SPECIFICATIONS
ST-WD650PTZMINI-12X
Specifications (Typical)
1.Image Sensor
1/3" Super HAD II Sony Color CCD
2
Resolution
Color 650TVL, Black 700TVL
3. Lens
5-60mm dynamic varifocal lens
4.
Effective Picture Elements
NTSC:976(H)×494(V)
5.
Minimum Illumination
0.001 Lux
6.
Scanning System
2:1 interlace
7.
Video Output
1Vpp, 75Ω
8. Signal to Noise Ratio
50dB
9.
Synchronous System
Internal, Negative sync.
10.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s,
11.
Gama Correction
0.45
12.
Gain Control
Auto
13.
White Balance
Auto / Manual
14.
Pan Range
360° continuous
15.
Tilt Range
0° ~ 90°
16.
Pan Speed
60° / second
17. Power
12VDC / 1A
18.
Storage Temperature
-22° F ~ 140° F
19.
Operating Temperature
14° F ~ 113° F
20.
Dimensions
8” x 8.5”
21.
Weight
2.9 lbs
