Installation manual

v1.0 1/19/11
2
PACKAGE CONTENTS
This package contains:
One ST-D600DN2812-DSHB Super WDR dome color camera with heater and blower
One installation manual
Mounting hardware and mounting template
One side cap
Video and external OSD control cable
RS485 terminal block
Note: The ST-D600DN2812-DSHB requires a minimum 12VDC 150mA (no heater or blower)
power supply such as the ST-PS12VDC1A or ST-PS12VDC2A. The camera may also operate at
24VAC 360mA (heater and blower on).
PRODUCT DESCRIPTION
The ST-D600DN2812-HB is a professional grade, WDR (Wide Dynamic Range) day and night
color dome camera designed to provide clear images even under intense back light conditions.
The camera uses a 1/3” SONY Color Vertical Double Density CCD, provides 600TV lines of
resolution in color and 700TV lines in B&W. The ST-D600DN2812-DSHB has a 2.8mm – 12mm
lens for wide or narrow viewing. The 3 axis mount, built-in RS485 connection and on-screen
display make this camera very easy to set up. The day and night feature supports low light
illumination down to 0.0008Lux. An integrated heater and blower make this camera perfect for all
weather applications. This is a dual voltage camera that can be powered with either 12VDC or
24VAC, however, 24VAC must be applied to activate the heater function.
SPECIFICATIONS
ST-D600DN2812-DSHB
Specifications (Typical)
1. Image Sensor
1/3” SONY Color Vertical Double Density CCD
2. Scanning System
NTSC
3. Horizontal Resolution
600TV Lines Color, 700TV Lines B&W
4. Synchronization
Internal H/V 15.734/59.94Hz
Line Lock H/V 15.750/60Hz
5. Minimum Illumination
Sens-Up Off 0.12Lux (15IRE), 0.2Lux (30IRE),
0.4Lux (50IRE) F1.2
Sens-Up On 0.0002Lux (15IRE), 0.0005Lux (30IRE),
0.0008Lux (50IRE) F1.2
6. Scanning System
2 :1 interlace
7. Auto Electronic Shutter
1/60s~1/100,000s
8. Auto Gain Control
Automatic Low, Middle, High, Off
9. Lens
Aspherical 2.8 – 12mm DC Auto Iris ICR lens
10. S/N Ratio
>52dB (AGC off)
11. Privacy Masking
8 Windows (Polygonal, 8 Colors)
12. Day & Night
Color, B&W, Auto, Ext
13. Motion Detection
On/Off
14. Digital Zoom
X1.0 – x10
15. Gamma Correction
0.45
16. Video Output
1.0Vp-p/75Ω
17. WDR Level
120dB Max.
