OWNER'S MANUAL ENFORCER 100LB 100CB • • (315 MHz) 100LB - 4 100CB - 4 (433.92 MHz) Remote Controlled Vehicle Security System SECO-LARM® U.S.A., INC. 16842 Millikan Avenue Irvine, California 92606 FILE: MOE100CFB.
ENFORCER 100LB/100CB Owner's Manual CONGRATULATIONS From the moment you purchased this ENFORCER Vehicle Security System, you became a part of the SECO-LARM family. You started taking advantage of over 34 years of advanced engineering. You joined a team of engineers, technicians, designers, and people like yourself who know how important protecting your car is. You discovered the SECO-LARM difference. This difference is important because the ENFORCER is more than just an alarm.
ENFORCER 100LB/100CB Owner's Manual TABLE OF CONTENTS Transmitter Functions ................................... ENFORCER 100LB or ENFORCER 100CB? .... Arming ......................................................... Armed .......................................................... Sensor Bypass .............................................. Zone Bypass ................................................. 2nd Channel Output ..................................... Total Protection .................................
ENFORCER 100LB/100CB Owner's Manual ARMING There are two different ways to arm your alarm. Tell your dealer which is best for you: Active Arming Turn your ignition OFF. Close all the doors. Then press the button. If the siren chirps and parking lights flash once, the alarm is fully armed and the doors lock.
ENFORCER 100LB/100CB Owner's Manual SENSOR BYPASS This is useful if you know, based on experience, that your shock sensor (or other add-on sensors) will false trigger, such as when you park near a construction site. Should you wish to bypass your alarm's sensors, first press the button to arm the alarm (even if the alarm is set for passive arming). The siren chirps and the parking lights flash once (three times if a zone is bypassed) to confirm armed. Within three seconds, press the button.
ENFORCER 100LB/100CB Owner's Manual TOTAL PROTECTION While your alarm is armed, your car is protected in the following ways: z Potential thieves or vandals will be warned by the flashing LED. z If a thief opens a door, the alarm immediately sounds the siren and flashes the parking lights for 30 seconds. If the opened door is not closed and current sensing has not been selected, the siren and lights will trigger up to four 30-second cycles, after which the alarm will rearm.
ENFORCER 100LB/100CB Owner's Manual VALET Sometimes you may not wish your alarm to arm when you leave your vehicle. (For instance, if you leave your car with a valet attendant, you may not want to teach him how the alarm operates.) If your alarm is set for active (manual) arming, this is easy — don’t press the button, and the alarm will not arm. However, if your alarm is set to arm passively, use the valet mode to prevent it from arming. To enter valet, first disarm the alarm and turn the ignition ON.
ENFORCER 100LB/100CB Owner's Manual CHIRP DELETE (silent arm/disarm) There are times, especially at night, when you may not want to hear the siren chirps. There are 2 ways to delete chirps: A. One-time delete — Just press the button any time before you need the chirps deleted. For instance, press the button before you press the button to arm the alarm, and the chirps will not sound, but the parking lights will still flash. The chirps are restored the next time you press any transmitter button. B.
ENFORCER 100LB/100CB Owner's Manual ANTI-CARJACK PROTECTION (optional) A. Enabling the ANTI-CARJACK function: If the ANTI-CARJACK toggle switch is not installed, you cannot use the ANTI-CARJACK function (please ask your dealer). To enable the ANTI-CARJACK function, put the ANTICARJACK toggle switch to the ON position. If the ANTI-CARJACK toggle switch is OFF, the ANTI-CARJACK function cannot be entered.
ENFORCER 100LB/100CB Owner's Manual TAMPER INDICATORS & TRIGGER ZONE ID If your alarm was triggered when you were away, the siren will chirp two times and the parking lights flash seven times when you disarm your alarm. The LED flashes in quick cycles to show where the car was violated as follows: z 1 flash — The ignition was turned on. z 2 flashes — The alarm was triggered via panic. z 3 flashes — The shock sensor or other add-on sensor was triggered. z 4 flashes — A door was opened.
ENFORCER 100LB/100CB Owner's Manual Appendix 1 — UNDERSTANDING THE SIREN CHIRPS AND LIGHT FLASHES A. 1 chirp/flash: z When the button is pressed, the alarm is armed. z When a door is closed, the alarm will arm in 30 seconds (passive arming). z 30 seconds after the ignition switch is turned OFF and all doors are closed (or delayed domelights turn OFF), the alarm is armed (passive arming). z Successfully entered the valet mode. B. 2 chirps/flashes: z When the button is pressed, the alarm is disarmed.
ENFORCER 100LB/100CB Owner's Manual Appendix 2 — UNDERSTANDING THE LED FLASHES A. Arming indicator — Flashes quickly during the 30-second rearm to show passive arming countdown. B. Door open indicator — OFF when a hardwired door is opened during the 30-second rearm or passive arming countdown. C. Armed indicator — Flashes when the alarm is armed. D. Disarmed indicator — OFF when the alarm is disarmed. E.
