Computer Drive - DVD/CD Drive User Manual
Table Of Contents
- Preface
- Electromagnetic susceptibility
- Electromagnetic compliance
- Electromagnetic compliance for the European Union
- Australian C-Tick
- Seagate Technology support services
- General description
- Initial setup information
- General information
- SCSI ID jumpers
- Drive termination
- Terminator power
- I/O circuits and data path widths
- Providing adequate cooling
- Mounting the drive and connecting cables
- Formatting the drive
- Quick reference desktop system notes
- Setting the SCSI ID jumpers
- Terminating the drive
- Terminator power
- Other applicable jumper options
- Setting the SCSI ID jumpers
- Terminating the drive
- Terminator power
- Other applicable jumper options
- Setting the SCSI ID jumpers
- Terminating the drive
- Applicable jumper options

18 Medalist Pro Installation Guide, Rev. B
[1] Can be operated according to SCSI-2/SCSI-3 protocols. Referred to
also as “SCSI Fast-20” or “Fast-40.”
[2] Includes controller overhead.
Table 2a. DC power requirements (Amps) for N/W/WC
models
ST39140
N/W/WC
ST36530
N/W/WC
ST34520
N/W/WC
Voltage +5V +12V +5V +12V +5V +12V
Regulation [5] ±5% ±5%[2] ±5% ±5%[2] ±5% ±5%[2]
Max. operating
current DC [1] 0.55 2.4 0.55 2.4 0.55 2.4
Avg. idle current
DCX
[1] 0.51 0.81 0.51 0.81 0.51 0.81
Max. starting
current
(peak DC) DC [3]
(peak AC) AC [3]
2.5
N/A
2.5
N/A
2.5
N/A
Delayed motor
start (max)
DC [1][4] 0.51 0.13 0.51 0.13 0.51 0.13
Peak operating
current
Typical DCX
[1][6]
Maximum DC [1]
0.51
0.55
0.96
1.17
0.51
0.55‘
0.96
1.17
0.51
0.55
0.96
1.17
