Cheetah NS 10K.2 FC Product Manual, Rev. B 57
[1] Cheetah NS 10K.2 FC drives can format to 512, 520, 524 or 528 bytes per logical block.
[2] Warning. Power loss during flash programming can result in firmware corruption. This usually makes the
drive inoperable.
[3] Reference Mode Sense command 1Ah for mode pages supported.
[4] Y = Yes. Command is supported.
N = No. Command is not supported.
A = Support is available on special request.
Y Temperature page (0Dh)
N Application Client page (0Fh)
Y Self Test Results page (10h)
Y Background Medium Scan page (15h)
Y Cache Statistics Counter page (37h)
Y Factory Log page (3Eh)
4E-4Fh N Not used
50h N XD write
51h N XP write
52h N XD read
53-54h N Not used
55h Y Mode Select (10) [3]
56h Y Reserved (10)
Y 3rd party reserve
N Extent reservation
57h Y Released (10)
58-59h N Not used
5Ah Y Mode Sense (10) [3]
5B-5Dh N Not used
5E A Persistent reserve in
5F A Persistent reserve out
60-7Fh N Not used
80h N XD write extended
81h N Rebuild
82h N Regenerate
83-8Fh N Not used
A0h Y Report LUNS
C0-DFh N Not used
EO-FFh N Not used
Table 16: Supported commands (continued)
Command code Supported [4] Command name
