54 Cheetah NS 10K.2 FC Product Manual, Rev. B
9.3 SCSI commands supported
Table 16 lists the SCSI commands supported by Cheetah NS 10K.2 FC drives.
Table 16: Supported commands
Command code Supported [4] Command name
00h Y Test unit ready
01h Y Rezero unit
03h Y Request sense
Y Extended sense
Y Field pointer bytes
Y Actual retry count bytes
04h Y Format unit [1]
07h Y Reassign blocks
08h Y Read
0Ah Y Write
0Bh Y Seek
12h Y Inquiry
Y Vital product data page (00h)
Y Unit serial number page (80h)
Y Implemented operating def. page (81h)
Y Device Identification page (83h)
Y Firmware numbers page (C0h)
Y Date code page (C1h)
Y Jumper settings page (C2h)
Y Device Behavior page (C3h)
15h Y Mode select (same pages as Mode Sense command shown below) [3]
16h Y Reserve
N 3rd party reserved
N Extent reservation
17h Y Release
18h N Copy
1Ah Y Mode sense
Y Unit attention page (00h)
Y Error recovery page (01h)
Y Disconnect/reconnect control (page 02h)
Y Format page (03h)
Y Rigid disk drive geometry page (04h)
