Cheetah NS 10K.2 FC Product Manual, Rev. B 51
9.1.7 Fibre Channel Process Login Accept
Table 12 lists Cheetah NS 10K.2 FC process login accept payload data.
9.1.8 Fibre Channel fabric login
Table 13 lists the fabric login payload from the drive.
Table 12: Process Login Accept (ACC) payload
Bytes
0-15 02 10 00 14 08 00 21 00 00 00 00 00 00 00 00 00
16-31 00000012
Table 13: Fabric Login (FLOGI) payload
Bytes
0-15 04 00 00 00 09 09 00 00 08 00 08 40 00 00 00 00 Common
16-31 000002F42P00CCCCCCUIUIUI 0200CCCC
32-35 CC UI UI UI
36-47 000000000000000000000000Class 1
48-51 00000000
52-63 000000000000000000000000Class 2
64-67 00000000
68-79 800000000000084000000000Class 3
80-83 00000000
84-95 000000000000000000000000Reserved
96-99 00000000
100-111 00 00 00 00 00 00 00 00 00 00 00 00 Vendor -
112-115 00 00 00 00 Version
CC Bytes (22, 23 and 24) and (30, 31 and 32) are currently factory set to 00 04 CF respectively (subject to change).
UI Unique identifier. This 24-bit field is uniquely assigned to the drive. This same UI appears in the Port Name and
Node Name fields.
P Port identifier field.
1 FLOGI originated on Port A.
2 FLOGI originated on Port B.
