Product Manual Cheetah NS 10K.2 FC ST3600002FC ST3450802FC ST3300602FC 100516227 Rev.
Copyright © 2009 Seagate Technology LLC. All rights reserved. Printed in U.S.A. Publication number: 100516227, Rev. B, July 2009 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Cheetah, SeaTools and SeaTDD are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/ or other countries.
Contents 1.0 Scope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2.0 Standards, compliance and reference documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.1 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.1.1 Electromagnetic compatibility. . . . . . . . . . . . . . . . . . . . . . . . . .
6.4.2 Relative humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.4.3 Effective altitude (sea level) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.4.4 Shock and vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.4.5 Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.4.6 Air cleanliness . . . . . .
9.6 10.0 9.5.12 Device control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Signal characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.6.1 TTL input characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.6.2 LED driver signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.6.
iv Cheetah NS 10K.2 FC Product Manual, Rev.
1.0 Scope This manual describes Seagate Technology® LLC, Cheetah NS 10K.2 FC (Fibre Channel) disk drives. Cheetah NS 10K.2 FC drives support the Fibre Channel Arbitrated Loop and SCSI Fibre Channel Protocol specifications to the extent described in this manual. The Fibre Channel Interface Manual (part number 100293070) describes the general Fibre Channel Arbitrated Loop characteristics of this and other Seagate Fibre Channel drives. Cheetah NS 10K.2 FC Product Manual, Rev.
2 Cheetah NS 10K.2 FC Product Manual, Rev.
2.0 Standards, compliance and reference documents The drive has been developed as a system peripheral to the highest standards of design and construction. The drive depends upon its host equipment to provide adequate power and environment in order to achieve optimum performance and compliance with applicable industry and governmental regulations. Special attention must be given in the areas of safety, power distribution, shielding, audible noise control, and temperature regulation.
2.2 Compliance 2.2.1 Electromagnetic compliance Seagate uses an independent laboratory to confirm compliance with the directives/standards for CE Marking and C-Tick Marking. The drive was tested in a representative system for typical applications. The selected system represents the most popular characteristics for test platforms. The system configurations include: • Typical current use microprocessor • 3.
2.3 Reference documents SCSI Commands Reference Manual Seagate part number: 100293068 Fibre Channel Interface Manual Seagate part number: 100293070 ANSI Fibre Channel Documents X3.230-1994 X3.297.1997 X3.303.1998 X3.272-1996 X3.
6 Cheetah NS 10K.2 FC Product Manual, Rev.
3.0 General description Cheetah NS 10K.2 FC drives provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. Cheetah NS 10K.2 FC drives support 4-Gbit Fibre Channel which can transfer data at up to 800 Mbytes per second and 1600 Mbytes per second in dual-loop configurations. Cheetah NS 10K.
3.
3.3 Performance • Programmable multi-segmentable cache buffer • 800 Mbytes/sec maximum instantaneous data transfers per port • 10k RPM spindle. Average latency = 2.98 msec • Command queuing of up to 128 commands • Background processing of queue • Supports start and stop commands (spindle stops spinning) • Adaptive seek velocity; improved seek performance 3.4 Reliability • Annualized Failure Rate (AFR) of 0.
3.6 Programmable drive capacity Using the Mode Select command, the drive can change its capacity to something less than maximum. See the Mode Select Parameter List table in the SCSI Commands Reference Manual. Refer to the Parameter list block descriptor number of blocks field. A value of zero in the number of blocks field indicates that the drive shall not change the capacity it is currently formatted to have.
4.0 Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Cheetah NS 10K.2 FC drives. 4.1 Internal drive characteristics Drive capacity* Read/write data heads Tracks per inch Peak bits per inch Areal density Internal data rate disk rotation speed Avg rotational latency ST3600002FC 600 8 165,000 1,347 225 1.01 to 1.84 10k 2.98 ST3450802FC 450 6 165,000 1,347 225 1.01 to 1.84 10k 2.98 ST3300602FC 300 4 165,000 1,347 225 1.
4.2.2 Format command execution time (minutes) ST3600002FC ST3450802FC ST3300602FC Maximum (with verify) 182 129 83 Maximum (without verify) 101 68 43 Execution time measured from receipt of the last byte of the Command Descriptor Block (CDB) to the request for a Status Byte Transfer to the Initiator (excluding connect/disconnect). When changing sector sizes, the format times shown above may need to be increased by 30 minutes. 4.2.
4.4 Prefetch/multi-segmented cache control The drive provides a prefetch (read look-ahead) and multi-segmented cache control algorithms that in many cases can enhance system performance. Cache refers to the drive buffer storage space when it is used in cache operations. To select this feature, the host sends the Mode Select command with the proper values in the applicable bytes in page 08h.
4.5.1 Caching write data Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored while the drive performs the Write command. If read caching is enabled (RCD=0), then data written to the medium is retained in the cache to be made available for future read cache hits. The same buffer space and segmentation is used as set up for read functions.
5.0 Reliability specifications The following reliability specifications assume correct host and drive operational interface, including all interface timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Read Error Rates1 Recovered Data Unrecovered Data Miscorrected Data Interface error rate: Mean Time Between Failures (MTBF) Annualized Failure Rate (AFR): Preventive maintenance: 1.
5.1.3 Seek errors A seek error is defined as a failure of the drive to position the heads to the addressed track. After detecting an initial seek error, the drive automatically performs an error recovery process. If the error recovery process fails, a seek positioning error (Error code = 15h or 02h) will be reported with a Hardware error (04h) in the Sense Key. Recoverable seek errors are specified at Less than 10 errors in 108 seeks.
The Pass-through state is disabled while the drive performs self test of the FC interface. The control line for an external port bypass circuit remains in the Enable Bypass state while self test is running. If the bypass circuit is present, loop operation may continue. If the bypass circuit is not present, loop operation will be halted while the self test of the FC interface runs.
Reporting control Reporting is controlled by the MRIE bits in the Informational Exceptions Control mode page (1Ch). Subject to the reporting method, the firmware will issue to the host an 01-5Dxx sense code. The error code is preserved through bus resets and power cycles. Determining rate S.M.A.R.T. monitors the rate at which errors occur and signals a predictive failure if the rate of degraded errors increases to an unacceptable level.
be used to set this trip point. The default value for this drive is 68°C, however, you can set it to any value in the range of 0 to 68°C. If you specify a temperature greater than 68°C in this field, the temperature is rounded down to 68°C. A sense code is sent to the host to indicate the rounding of the parameter field. Table 1: Temperature Log Page (0Dh) Parameter Code Description 0000h Primary Temperature 0001h Reference Temperature 5.2.
A Drive Not Ready condition is reported by the drive under the following conditions: • • • • Motor will not spin Motor will not lock to speed Servo will not lock on track Drive cannot read configuration tables from the disk In these conditions, the drive responds to a Test Unit Ready command with an 02/04/00 or 02/04/03 code. 5.2.6.2.
The drive will report the failure condition and LBA (if applicable) in the Self-test Results Log parameter. The Sense key, ASC, ASCQ, and FRU are used to report the failure condition. 5.2.6.2.5 Abort There are several ways to abort a diagnostic. You can use a SCSI Bus Reset or a Bus Device Reset message to abort the diagnostic. You can abort a DST executing in background mode by using the abort code in the DST Function Code field.
22 Cheetah NS 10K.2 FC Product Manual, Rev.
6.0 Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the drive. 6.1 AC power requirements None. 6.2 DC power requirements The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector. Notes are shown following table 4.
Table 3: DC power requirements for ST3450802FC model 1 Gbit Notes Voltage 2 Gbit 4 Gbit (Amps) (Amps) (Amps) (Amps) (Amps) (Amps) +5V +12V [4] +5V +12V [4] +5V +12V [4] Regulation [5] ±5% ±5% [2] ±5% ±5% [2] ±5% ±5% [2] Avg idle current DCX [] [7] 0.36 0.33 0.38 0.33 0.40 0.33 Maximum starting current (peak DC) DC 3σ [5] 0.45 1.94 0.47 1.92 0.64 1.95 (peak AC) AC 3σ [5] 0.76 4.22 0.92 4.16 1.04 4.16 [] [6] 0.44 0.04 0.46 0.04 0.49 0.04 [] [6] 0.
Table 4: DC power requirements for ST3300602FC model 1 Gbit Notes Voltage 2 Gbit 4 Gbit (Amps) (Amps) (Amps) (Amps) (Amps) (Amps) +5V +12V [4] +5V +12V [4] +5V +12V [4] Regulation [5] ±5% ±5% [2] ±5% ±5% [2] ±5% ±5% [2] Avg idle current DCX [] [7] 0.36 0.31 0.38 0.30 0.40 0.30 Maximum starting current (peak DC) DC 3σ [5] 0.44 1.94 0.46 1.95 0.63 1.95 (peak AC) AC 3σ [5] 0.84 3.98 0.74 3.64 1.02 3.66 [] [6] 0.44 0.04 0.46 0.04 0.48 0.04 [] [6] 0.
6.2.1 Conducted noise immunity Noise is specified as a periodic and random distribution of frequencies covering a band from DC to 10 MHz. Maximum allowed noise values given below are peak-to-peak measurements and apply at the drive power connector. +5 V = +12 V = 250 mV pp from 0 to 100 kHz to 20 MHz. 800 mV pp from 100 Hz to 8 KHz. 450 mV pp from 8 KHz to 20 KHz. 250 mV pp from 20 KHz to 5 MHz. 6.2.2 Power sequencing The drive does not require power sequencing.
Figure 2. Typical ST3450802FC drive, 4 Gbit, +5V and +12V current profiles Cheetah NS 10K.2 FC Product Manual, Rev.
Figure 3. 28 Typical ST3300602FC drive, 4 Gbit, +5V and +12V current profiles Cheetah NS 10K.2 FC Product Manual, Rev.
6.3 Power dissipation ST3600002FC Typical power dissipation under idle conditions in 4 Gbit operation is 6.55 watts (22.33 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 4.
ST3450802FC Typical power dissipation under idle conditions in 4 Gbit operation is 5.92 watts (20.21 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 5.
ST3300602FC Typical power dissipation under idle conditions in 4 Gbit operation is 5.50 watts (18.76 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 6.
6.4 Environmental limits Temperature and humidity values experienced by the drive must be such that condensation does not occur on any drive part. Altitude and atmospheric pressure specifications are referenced to a standard day at 58.7°F (14.8°C). Maximum wet bulb temperature is 82°F (28°C). 6.4.1 Temperature a. Operating The maximum allowable continuous or sustained HDA case temperature for the rated Annualized Failure Rate (AFR) is 122°F (50°C) The maximum allowable HDA case temperature is 60°C.
6.4.3 Effective altitude (sea level) a. Operating –1,000 to +10,000 feet (–305 to +3,048 meters) b. Non-operating –1,000 to +40,000 feet (–305 to +12,192 meters) 6.4.4 Shock and vibration Shock and vibration limits specified in this document are measured directly on the drive chassis. If the drive is installed in an enclosure to which the stated shock and/or vibration criteria is applied, resonances may occur internally to the enclosure resulting in drive movement in excess of the stated limits.
d. Packaged Disk drives shipped as loose load (not palletized) general freight will be packaged to withstand drops from heights as defined in the table below. For additional details refer to Seagate specifications 30190-001 (under 100 lbs/45 kg) or 30191-001 (over 100 lbs/45 Kg). Package size Packaged/product weight Drop height <600 cu in (<9,800 cu cm) 600-1800 cu in (9,800-19,700 cu cm) >1800 cu in (>19,700 cu cm) >600 cu in (>9,800 cu cm) Any 0-20 lb (0 to 9.1 kg) 0-20 lb (0 to 9.1 kg) 20-40 lb (9.
6.4.4.2 Vibration a. Operating—normal The drive as installed for normal operation, shall comply with the complete specified performance while subjected to continuous vibration not exceeding 10 - 300 Hz 301 - 500 Hz 1 G RMS (0 to peak) 0.5 G RMS (0 to peak) Vibration may be applied in the X, Y, or Z axis. b.
should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. Materials used in cabinet fabrication, such as vulcanized rubber, that can outgas corrosive compounds should be minimized or eliminated. The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives. 6.4.
6.5 Mechanical specifications Refer to Figure 9 for detailed physical dimensions. See Section 8.4, “Drive mounting.” Height (max): Width (max): Depth (max): Weight (max): Figure 9. 1.013 in 3.999 in 5.769 in 1.482 pounds 25.73 mm 101.57 mm 146.53 mm 0.672 kilograms Mounting configuration dimensions Cheetah NS 10K.2 FC Product Manual, Rev.
38 Cheetah NS 10K.2 FC Product Manual, Rev.
7.0 Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and FC system error considerations (errors in communications between the initiator and the drive).
The drive firmware error recovery algorithms consists of 11 levels for read recoveries and five levels for write. Each level may consist of multiple steps, where a step is defined as a recovery function involving a single reread or re-write attempt. The maximum level used by the drive in LBA recovery is determined by the read and write retry counts. Table 5 equates the read and write retry count with the maximum possible recovery time for read and write recovery of individual LBAs.
7.3 FC-AL system errors Information on the reporting of operational errors or faults across the interface is given in the Fibre Channel Interface Manual. The FCP Response returns information to the host about numerous kinds of errors or faults. The Receive Diagnostic Results reports the results of diagnostic operations performed by the drive. Status returned by the drive to the initiator is described in the Fibre Channel Interface Manual.
7.6 Deferred Auto-Reallocation Deferred Auto-Reallocation (DAR) simplifies reallocation algorithms at the system level by allowing the drive to reallocate unreadable locations on a subsequent write command. Sites are marked for DAR during read operations performed by the drive. When a write command is received for an LBA marked for DAR, the auto-reallocation process is invoked and attempts to rewrite the data to the original location.
8.0 Installation Cheetah NS 10K.2 FC disk drive installation is a plug-and-play process. There are no jumpers, switches, or terminators on the drive. Simply plug the drive into the host’s 40-pin Fibre Channel backpanel connector (FCSCA)—no cables are required. See Section 9.5 for additional information about this connector. Use the FC-AL interface to select drive ID and all option configurations for devices on the loop.
If forced air is necessary, possible air-flow patterns are shown in Figure 10. The air-flow patterns are created by fans either forcing or drawing air as shown in the illustrations. Conduction, convection, or other forced airflow patterns are acceptable as long as the temperature measurement guidelines of Section 6.4.1 are met. Above unit Note. Air flows in the direction shown (back to front) or in reverse direction (front to back) Under unit Above unit Note.
8.5 Grounding Signal ground (PCBA) and HDA ground are connected together in the drive and cannot be separated by the user. The equipment in which the drive is mounted is connected directly to the HDA and PCBA with no electrically isolating shock mounts. If it is desired for the system chassis to not be connected to the HDA/PCBA ground, the systems integrator or user must provide a nonconductive (electrically isolating) method of mounting the drive in the host equipment.
46 Cheetah NS 10K.2 FC Product Manual, Rev.
9.0 Interface requirements This section partially describes the interface requirements as implemented on Cheetah NS 10K.2 FC drives. Additional information is provided in the Fibre Channel Interface Manual (part number 100293070). 9.1 FC-AL features This section lists the Fibre Channel-specific features supported by Cheetah NS 10K.2 FC drives. 9.1.1 Fibre Channel link service frames Table 6 lists the link services supported by Cheetah NS 10K.2 FC drives.
9.1.2 Fibre Channel task management functions Table 7 lists the Fibre Channel SCSI Fibre Channel Protocol (FC SCSI FCP) task management functions supported. Table 7: Fibre Channel SCSI FCP task management functions Task name Supported Terminate task No Clear ACA Yes Target reset Yes Clear task set Yes Abort task set Yes 9.1.3 Fibre Channel task management responses Table 8 lists the FC SCSI FCP response codes returned for task management functions supported.
9.1.4 Fibre Channel port login Table 9 identifies the required content of the N_Port Login (PLOGI) payload from an initiator.
9.1.5 Fibre Channel port login accept Table 10 identifies the N_Port Login access payload values.
9.1.7 Fibre Channel Process Login Accept Table 12 lists Cheetah NS 10K.2 FC process login accept payload data. Table 12: Process Login Accept (ACC) payload Bytes 0-15 02 10 00 14 16-31 00 00 00 12 9.1.8 08 00 21 00 00 00 00 00 00 00 00 00 Fibre Channel fabric login Table 13 lists the fabric login payload from the drive.
9.1.9 Fibre Channel fabric accept login Table 14 lists the required content of the Fabric Login Accept (ACC) payload from the fabric.
9.1.10 Fibre Channel Arbitrated Loop options Table 15 lists the FC-AL options supported by Cheetah NS 10K.2 FC drives. Table 15: FC-AL options supported Option Supported OPEN Half Duplex Accepted from another device. OPEN Full Duplex Sent to open another device. Accepted from another device. Private Loop Yes Public Loop Yes Old Port State No Loop Position Yes Loop Position Report Yes 9.2 Dual port support Cheetah NS 10K.2 FC drives have two independent FC-AL ports.
9.3 SCSI commands supported Table 16 lists the SCSI commands supported by Cheetah NS 10K.2 FC drives.
Table 16: Supported commands (continued) Command code Supported [4] Command name Y Verify error recovery page (07h) Y Caching parameters page (08h) Y Control mode page (0Ah) Y Fibre Channel Interface Control page (19h) Y Power control page (1Ah) Y Information exceptions control page (1Ch) Y Background Scan mode subpage (01h) 1Bh Y Start unit/stop unit 1Ch Y Receive diagnostic results Y Supported diagnostics pages Y Translate page Y Enclosure services page Y Send diagnostics p
Table 16: Supported commands (continued) Command code Supported [4] Command name 32h N Search data low 33h N Set limits 34h N Prefetch 35h Y Synchronize cache 36h N Lock-unlock-cache 37h Y Read defect data 39h N Compare 3Ah N Copy and verify 3Bh Y Write buffer Y Write combined header and data mode (0) Y Write data mode (2) N Download microcode mode (4) Y Download microcode and save modes (5) N Download microcode with offsets mode (6) Y Download microcode with offse
Table 16: Supported commands (continued) Command code Supported [4] Command name Y Temperature page (0Dh) N Application Client page (0Fh) Y Self Test Results page (10h) Y Background Medium Scan page (15h) Y Cache Statistics Counter page (37h) Y Factory Log page (3Eh) 4E-4Fh N Not used 50h N XD write 51h N XP write 52h N XD read 53-54h N Not used 55h Y Mode Select (10) [3] 56h Y Reserved (10) Y 3rd party reserve N Extent reservation 57h Y Released (10) 58-59h N
9.3.1 Inquiry data Table 17 lists the Inquiry command data that the drive should return to the initiator per the format given in the Fibre Channel Interface Manual. Table 17: Cheetah NS 10K.
On standard OEM drives, the saved values are taken from the default values list and stored into the saved values storage location on the media prior to shipping. 3. Current values Current values are volatile values being used by the drive to control its operation. A Mode Select command can be used to change the values identified as changeable values. Originally, current values are installed from saved or default values after a power on reset, hard reset, or Bus Device Reset message. 4.
Table 18: Mode Sense data saved, default and changeable values for ST3600002FC drives MODE DATA HEADER 00 00 05 12 8B 00 70 02 MODE SENSE PAGES DATA DEF 80 06 00 80 0F 00 00 00 CHG 80 06 B7 C0 8F 00 00 00 DEF 81 0A C0 0B FF 00 00 00 05 00 FF FF CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF DEF 82 0E 80 80 00 00 00 00 00 00 01 3A 00 00 00 00 CHG 82 0E FF FF 00 00 00 00 00 00 FF FF 00 00 00 00 DEF 83 16 BB D0 00 00 00 00 03 80 04 C4 02 00 00 01 00 60 00 26 40 00 00 00 CHG 83 16 00 00 00 00 00 00 FF FF 00 00 00 00
Table 19: Mode Sense data default and changeable values for ST3450802FC drives MODE DATA HEADER 00 00 05 12 8B 00 70 02 MODE PAGES DEF 80 06 00 80 0F 00 00 00 CHG 80 06 B7 C0 8F 00 00 00 DEF 81 0A C0 0B FF 00 00 00 05 00 FF FF CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF DEF 82 0E 80 80 00 00 00 00 00 00 01 3A 00 00 00 00 CHG 82 0E FF FF 00 00 00 00 00 00 FF FF 00 00 00 00 DEF 83 16 BB D0 00 00 00 00 03 80 04 C4 02 00 00 01 00 60 00 26 40 00 00 00 CHG 83 16 00 00 00 00 00 00 FF FF 00 00 00 00 00 00 00 00 00 00
Table 20: Mode Sense data default and changeable values for ST3300602FC drives MODE DATA HEADER 00 00 05 12 8B 00 50 02 MODE PAGES DEF 80 06 00 80 0F 00 00 00 CHG 80 06 B7 C0 8F 00 00 00 DEF 81 0A C0 0B FF 00 00 00 05 00 FF FF CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF DEF 82 0E 80 80 00 00 00 00 00 00 01 3A 00 00 00 00 CHG 82 0E FF FF 00 00 00 00 00 00 FF FF 00 00 00 00 DEF 83 16 BB D0 00 00 00 00 03 80 04 C4 02 00 00 01 00 60 00 26 40 00 00 00 CHG 83 16 00 00 00 00 00 00 FF FF 00 00 00 00 00 00 00 00 00 00
9.4 Miscellaneous operating features and conditions Table 21 lists various features and conditions. A “Y” in the support column indicates the feature or condition is supported. An “N” in the support column indicates the feature or condition is not supported.
9.5 FC-AL physical interface Figure 11 shows the location of the J1 Fibre Channel single connection attachment (FC-SCA). Figure 13 provides the dimensions of the FC-SCA connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s Fibre Channel drives are provided in the Fibre Channel Interface Manual.. J1 interface connector Figure 11. Physical interface 9.5.
9.5.2 Connector requirements The FC-AL SCA device connector is illustrated in Figure 13. Figure 13. FC-AL SCA device connector dimensions 9.5.3 Electrical description Fibre Channel drives use the FC-SCA connector for: • • • • • DC power FC-AL interface Drive select (device identification) Option selection Enclosure Services interface This 40-pin connector is designed to plug directly into a backpanel. External cables are not required. 9.5.
Table 23: FC-SCA pin descriptions Pin Signal name Signal type Pin Signal name 1* -EN bypass port A Low Voltage TTL output 21 12 Volts charge 2* 12 Volts 22 Ground 3* 12 Volts 23 Ground 4* 12 Volts 24* +Port A_in 5* -Parallel ESI 25* -Port A_in 6* Ground[1] 26 Ground 7* Active LED out 27* +Port B_in 8* Reserved 28* -Port B_in 9* [2] TTL input 29 Ground [2] Start_1 Open collector out Signal type FC Diff. input pair FC Diff.
9.5.6 Power Power is supplied through the FC-SCA with support for +5 volts and +12 volts. All of the voltage pins in the drive connector are the same length. Four 12 volt pins provide +12 volt power to the drive. The current return for the +12 volt power supply is through the common ground pins. The supply current and return current must be distributed as evenly as possible among the pins. The maximum current typically occurs while the drive motor is starting.
9.5.8 Active LED Out The Active LED Out signal is driven by the drive as indicated in Table 24.
Table 25: Motor start control signals Case Start_2 Start_1 Motor spin function 4 High High The drive will not spin up. 9.5.11 SEL_6 through SEL_0 ID lines The SEL_6 through SEL_0 ID lines determine drive address, and, optionally, for an Enclosure Services Interface. When the Parallel ESI line is high, the enclosure backpanel must provide address information on the SEL line. Refer to table 26 for a mapping of SEL to FC-AL physical addresses (AL_PA).
Table 26: Arbitrated loop physical address (AL_PA) values AL_PA (hex) SEL ID (hex) Setting (dec) AL_PA (hex) SEL ID (hex) Setting (dec) AL_PA (hex) SEL ID (hex) Setting (dec) EF E8 E4 E2 00 01 02 03 00 01 02 03 A3 9F 9E 9D 2B 2C 2D 2E 43 44 45 46 4D 4C 4B 4A 56 57 58 59 86 87 88 89 E1 E0 DC DA D9 D6 D5 D4 D3 D2 04 05 06 07 08 09 0A 0B 0C 0D 04 05 06 07 08 09 10 11 12 13 9B 98 97 90 8F 88 84 82 81 80 2F 30 31 32 33 34 35 36 37 38 47 48 49 50 51 52 53 54 55 56 49 47 46 45 43 3c 3A 39
9.5.12 Device control codes The drive inputs a Device Control Code on the DEV_CTRL_CODE lines at power up to determine the link rate on the Fibre Channel ports. Both ports run at the same rate. If the backpanel does not connect to these lines, the drive has 10K ohm pull up resistors that default the device control code to 7 (1.0625 GHz). Table lists the supported codes. Table 27: Device control code values 2 (pin 17) 1 (pin 18) 0 (pin 39) Definition 0 0 0 Reserved for power failure warning.
9.6.2 LED driver signals Fault and Active LED signals are located in the FC-SCA connector (J1). See Table 29 for the output characteristics of the LED drive signals. Table 29: LED drive signal State Current drive available LED off, high 0 < IOH < 100µA LED on, low IOL < -30 mA 9.6.3 Output voltage 0 < VOL < 0.8V FC Differential output The serial output signal voltage characteristics are provided in Table 30.
Figure 16 provides the data valid eye diagram for typical and minimum requirements to recover data at the specified interface error rate. The inputs are AC coupled on the drive. Vin (mv) 941 ps 659 ps Typical 376 ps Minimum Figure 16. Receive eye diagram Table 32: Eye diagram data values Link rate 1 GHz 2 GHz 4 GHz Bit time 941 ps 470 ps 235 ps XMIT eye 725 ps min. 315 ps min. 1581/1132 Typical 659 ps 305 ps 145 ps Minimum 395 ps 226 ps 113 ps RCV eye 1. 2. Short Ideal load.
74 Cheetah NS 10K.2 FC Product Manual, Rev.
10.0 Seagate Technology support services Internet For information regarding Seagate products and services, visit www.seagate.com. Worldwide support is available 24 hours daily by email for your questions. Presales Support: Presales@Seagate.com Technical Support: DiscSupport@Seagate.com Warranty Support: http://www.seagate.com/www/en-us/support/warranty_&_returns_assistance mySeagate my.seagate.com is the industry's first Web portal designed specifically for OEMs and distributors.
Customer Service Operations Warranty Service Seagate offers worldwide customer support for Seagate products. Seagate distributors, OEMs and other direct customers should contact their Seagate Customer Service Operations (CSO) representative for warrantyrelated issues. Resellers or end users of drive products should contact their place of purchase or Seagate warranty service for assistance. Have your serial number and model or part number available.
