Seagate Enterprise Capacity 3.5 HDD v5 Serial ATA Product Manual, Rev. G 32
63 Multiword DMA active and modes supported (see note following this table) xx07
H
64 Advanced PIO modes supported (modes 3 and 4 supported) 0003
H
65 Minimum multiword DMA transfer cycle time per word (120 ns) 0078
H
66 Recommended multiword DMA transfer cycle time per word (120 ns) 0078
H
67 Minimum PIO cycle time without IORDY flow control (240 ns) 0078
H
68 Minimum PIO cycle time with IORDY flow control (120 ns) 0078
H
69 Additional supported 0008
H
70–74 ATA-reserved 0000
H
75 Queue depth 001F
H
76 Serial ATA capabilities 8D0E
H
77 (Bit 6:1) Send/Receive FPDMA Queued Commands Supported xx4x
H
78 Serial ATA features supported xxxx
H
79 Serial ATA features enabled xxxx
H
80 Major version number 07F0
H
81 Minor version number 0060
H
82 Command sets supported 306B
H
83 Command sets supported 7561
H
84 Command sets support extension (see note following this table)
6173
H
85 Command sets enabled 3069
H
86 Command sets enabled B441
H
87 Command sets enable extension 6173
H
88 Ultra DMA support and current mode (see note following this table) xx7F
H
89 Security erase time xxxx
H
90 Enhanced security erase time xxxx
H
92 Master password revision code FFFE
H
93 Hardware reset value xxxx
H
95–99 ATA-reserved 0000
H
100–103
Total number of user-addressable LBA sectors available (see Section 2.2 for
related information). These words are required for drives that support the 48-bit
addressing feature. Maximum value: 0000FFFFFFFFFFFFh.
ST8000NM0045 = 1,953,506,646
ST8000NM0055 = 15,628,053,168
ST8000NM0105 = 15,628,053,168
ST8000NM0115 = 1,953,506,646
ST8000NM0145 = 15,628,053,168
ST8000NM0155 = 1,953,506,646
ST8000NM0165 = 15,628,053,168
ST6000NM0055 = 1,465,130,646
ST6000NM0065 = 11,721,045,168
ST6000NM0155 = 11,721,045,168
ST6000NM0165 = 1,465,130,646
104–105 ATA-reserved 0000
H
106 Physical/Logical sector size 6003
H
107 ATA-reserved 0000
H
Word Description Value
