Seagate Enterprise Capacity 3.5 HDD v5 Serial ATA Product Manual, Rev. G 23
3.4.1 Mechanical specifications
Refer to Figure 6 for detailed mounting configuration dimensions. See Section 3.4, “Drive mounting.”
Figure 6. Mounting configuration dimensions (8TB and 6TB models)
Weight:
8TB models
1.72 lb 780 g
6TB models
Note
These dimensions conform to the Small Form Factor Standard documented
in SFF-8301 and SFF-8323, found at www.sffcommittee.or
g
Note
The image is for mechanical dimension reference only and may not represent the actual drive.
3.750±.010
2X 1.625±.020
2X 3.000±.010
.127±.010
4.000±.010
1.432±.019
2
.814±.020
2
4X 6-32 UNC 2B
3 MIN THREAD DEPTH
.1 MAX FASTENER PENETRATION
MOUNTING HOLE.
MAX TORQUE 6 IN/LBS
Y
B
5.787 MAX
146.99 MM
.250±.010
2X 4.000±.010
2X 1.122±.020
2X 6-32 UNC 2B
3 MIN THREAD DEPTH
.1 MAX FASTENER PENETRATION
MOUNTING HOLES BOTH SIDES.
MAX TORQUE 6 IN/LBS
Z
Y
1.028 MAX
26.11 MM
.142±.015
2
2.000
C
L
OF DRIVE
C
L
OF DRIVE
C
L
OF CONN
Z
TEMPERATURE
CHECKPOINT 60°C MAX
