Enterprise Capacity 3.5 HDD v5 SATA Product Manual Standard 4KN models Standard 512E models ST8000NM0045 ST8000NM0055 ST6000NM0055 ST6000NM0065 Standard Power Balance 4KN models ST8000NM0165 Self-Encryption 4KN models Self-Encryption 512E models ST8000NM0115 ST8000NM0105 ST6000NM0165 ST6000NM0155 SED FIPS 4KN models SED FIPS 512E models ST8000NM0145 ST8000NM0155 100780701, Rev.
Document Revision History Revision Date Pages affected and Description of changes Rev. A 10/29/2015 Initial release. Rev. B 03/29/2016 7: Changed “Ambient temperature” to “Drive case temperature” 10: Removed “Peak” from DC Power table 18: Updated Australian RCM statement 20: Updated Storage statement Rev. C 04/18/2016 fc, 5, 7, 9 & 31: Added SED FIPS models 26: Added Section 5.0 About FIPS Rev.
Contents Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.1 About the Serial ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents 3.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3.1 Handling and static-discharge precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3.2 Configuring the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3.
Seagate® Technology Support Services For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Enterprise Capacity 3.
1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following: Seagate® Enterprise Capacity 3.5 HDD v5 Serial ATA model drives:.
1.1 About the Serial ATA interface The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include: • Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options. • Thinner and more flexible cabling for improved enclosure airflow and ease of installation. • Scalability to higher performance levels.
2.0 Drive specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models:. Standard 4KN models Standard Power Balance 4KN models Self-Encrypting 4KN (SED) models SED FIPS 140-2 4KN models ST8000NM0045 ST8000NM0165 ST8000NM0115 ST8000NM0145 ST6000NM0055 2.
Drive specification ST8000NM0045, ST8000NM0055, ST8000NM0105, ST8000NM0115, ST8000NM0145, ST8000NM0155, ST8000NM0165 ST6000NM0055, ST6000NM0065, ST6000NM0155, ST6000NM0165 20°C (operating) 30°C (nonoperating) Temperature gradient (°C per hour max) 5% to 95% (operating) 5% to 95% (nonoperating) Relative humidity Relative humidity gradient 30% per hour max Altitude, operating –304.8 m to 3,048 m (–1000 ft to 10,000+ ft) Altitude, nonoperating (below mean sea level, max) –304.
2.2 Formatted capacity Formatted capacity* Guaranteed sectors ST8000NM0045, ST8000NM0115, ST8000NM0145 8TB 1,953,506,646 ST6000NM0055, ST6000NM0165 6TB 1,465,130,646 ST8000NM0055, ST8000NM0105, ST8000NM0155, ST8000NM0165 8TB 15,628,053,168 ST6000NM0065, ST6000NM0155 6TB ST models Bytes per logical sector 4096 512 11,721,045,168 *One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. 2.2.
2.5 Power specifications The drive receives DC power (+5V or +12V) through a native SATA power connector. See Figure 4 on page 22. 2.5.1 Power consumption Power requirements for the drives are listed in Table 2. Typical power measurements are based on an average of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature. Table 2 DC power requirements (8TB and 6TB) 6.0Gb mode Voltage +5V Regulation Avg Idle Current * +12V ± 5% Watts Total 0.29 0.
2.5.1.1 Typical current profiles Figure 1. 8TB and 6TB Typical 5V startup and operation current profile Figure 2. 8TB and 6TB Typical 12V startup and operation current profile Seagate Enterprise Capacity 3.5 HDD v5 Serial ATA Product Manual, Rev.
2.5.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12 V line or an equivalent 15-ohm resistive load on the +5V line. • Using 12V power, the drive is expected to operate with a maximum of 120mV peak-to-peak square-wave injected noise at up to 10MHz. • Using 5V power, the drive is expected to operate with a maximum of 100mV peak-to-peak square-wave injected noise at up to 10MHz.
Power Condition Log reports the following for each power condition • Nominal recovery time from the power condition to active • If the power condition is Supported, Changeable, and Savable • Default enabled state, and timer value • Saved enabled state, and timer value • Current enabled state, and timer value S.M.A.R.T.
2.6 Environmental limits Temperature and humidity values experienced by the drive must be such that condensation does not occur on any drive part. Altitude and atmospheric pressure specifications are referenced to a standard day at 58.7°F (14.8°C). To maintain optimal performance drives should be run at nominal drive temperatures and humidity. Note 2.6.1 Temperature a. Operating 41°F to 140°F (5°C to 60°C) drive case temperature range with a maximum temperature gradient of 36°F (20°C) per hour.
2.6.4 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. Shock may be applied in the X, Y or Z axis. 2.6.4.1 Operating shock These drives comply with the performance levels specified in this document when subjected to a maximum operating shock of 70 Gs (read) and 40 Gs (write) based on half-sine shock pulses of 2ms. Shocks should not be repeated more than two times per second. 2.6.4.
2.7 Acoustics Drive acoustics are measured as overall A-weighted acoustic sound power levels (no pure tones). All measurements are consistent with ISO document 7779. Sound power measurements are taken under essentially free-field conditions over a reflecting plane. For all tests, the drive is oriented with the cover facing upward. For seek mode tests, the drive is placed in seek mode only. The number of seeks per second is defined by the following equation: Note (Number of seeks per second = 0.
2.10 Reliability 2.10.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF) The production disk drive shall achieve an annualized failure-rate of 0.44% (MTBF of 2,000,000 hours) over a 5 year service life when used in Enterprise Storage field conditions as limited by the following: • 8760 power-on hours per year.
2.11.3 Australian RCM Compliance Mark If these models have the RCM marking, they comply with the Australia/New Zealand Standard AS/NZ CISPR32 and meet the Electromagnetic Compatibility (EMC) Framework requirements of the Australian Communication and Media Authority (ACMA). 2.11.4 Canada ICES-003 If this model has the ICES-003:2016 marking it complies with requirements of ICES tested per ANSI C63.4-2014. 2.11.
2.11.8 FCC verification These drives are intended to be contained solely within a personal computer or similar enclosure (not attached as an external device). As such, each drive is considered to be a subassembly even when it is individually marketed to the customer. As a subassembly, no Federal Communications Commission verification or certification of the device is required.
2.12.2 China Requirements —China RoHS 2 China RoHS 2 refers to the Ministry of Industry and Information Technology Order No. 32, effective July 1, 2016, titled Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products.
2.13 Corrosive environment Seagate electronic drive components pass accelerated corrosion testing equivalent to 10 years exposure to light industrial environments containing sulfurous gases, chlorine and nitric oxide, classes G and H per ASTM B845. However, this accelerated testing cannot duplicate every potential application environment.
3.0 Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. 3.1 Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution 3.
3.4.1 Mechanical specifications Refer to Figure 6 for detailed mounting configuration dimensions. See Section 3.4, “Drive mounting.” 8TB models 6TB models Weight: Note 1.72 lb 780 g These dimensions conform to the Small Form Factor Standard documented in SFF-8301 and SFF-8323, found at www.sffcommittee.org 4X 6-32 UNC 2B 3 MIN THREAD DEPTH .1 MAX FASTENER PENETRATION MOUNTING HOLE. MAX TORQUE 6 IN/LBS 2X 4.000±.010 2X 3.000±.010 5.787 MAX 146.99 MM 2X 1.625±.020 1.432±.019 2 .127±.010 2X 1.
4.0 About self-encrypting drives Self-encrypting drives (SEDs) offer encryption and security services for the protection of stored data, commonly known as “protection of data at rest.” These drives are compliant with the Trusted Computing Group (TCG) Enterprise Storage Specifications as detailed in Section 2.14. The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry.
4.3 Random number generator (RNG) The drive has a 32-byte hardware RNG that it is uses to derive encryption keys or, if requested to do so, to provide random numbers to the host for system use, including using these numbers as Authentication Keys (passwords) for the drive’s Admin and Locking SPs. 4.4 Drive locking In addition to changing the passwords, as described in Section 4.2.3, the owner should also set the data access controls for the individual bands.
4.8 Power requirements The standard drive models and the SED drive models have identical hardware, however the security and encryption portion of the drive controller ASIC is enabled and functional in the SED models. This represents a small additional drain on the 5V supply of about 30mA and a commensurate increase of about 150mW in power consumption. There is no additional drain on the 12V supply. See the tables in Section 2.5 for power requirements on the standard (non-SED) drive models. 4.
5.0 About FIPS The Federal Information Processing Standard (FIPS) Publication 140-2 is a U.S. Government Computer Security Standard used to accredit cryptographic modules. It is titled 'Security Requirements for Cryptographic Modules (FIPS PUB 140-2)' and is issued by the National Institute of Standards and Technology (NIST).
6.0 Serial ATA (SATA) interface These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed input/ output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6. For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. 6.1 Hot-Plug compatibility Enterprise Capacity 3.
6.3 Supported ATA commands The following table lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA: High Speed Serialized AT Attachment specification. See “S.M.A.R.T. commands” on page 36.for details and subcommands used in the S.M.A.R.T. implementation.
Command name Command code (in hex) Security Freeze F5H Security Set Password F1H Security Unlock F2H Seek 70H Send FPDMA Queued 64H Set Date & Time Ext 77H Set Features EFH Set Multiple Mode C6H Sleep E6H S.M.A.R.T. Disable Operations B0H / D9H S.M.A.R.T. Enable/Disable Autosave B0H / D2H S.M.A.R.T. Enable Operations B0H / D8H S.M.A.R.T. Execute Offline B0H / D4H S.M.A.R.T. Read Attribute Thresholds B0H / D1H S.M.A.R.T. Read Data B0H / D0H S.M.A.R.T.
6.3.1 Identify Device command The Identify Device command (command code ECH) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in Table 8 on page 29. All reserved bits or words should be set to zero. Parameters listed with an “x” are drive-specific or vary with the state of the drive. See Section 2.0 on page 7 for default parameter settings.
Word Description Value 63 Multiword DMA active and modes supported (see note following this table) xx07H 64 Advanced PIO modes supported (modes 3 and 4 supported) 0003H 65 Minimum multiword DMA transfer cycle time per word (120 ns) 0078H 66 Recommended multiword DMA transfer cycle time per word (120 ns) 0078H 67 Minimum PIO cycle time without IORDY flow control (240 ns) 0078H 68 Minimum PIO cycle time with IORDY flow control (120 ns) 0078H 69 Additional supported 0008H 70–74 ATA-res
Word Description Value 108–111 The mandatory value of the world wide name (WWN) for the drive. NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. Each drive will have a unique value.
Description (if bit is set to 1) Bit Word 63 0 Multiword DMA mode 0 is supported. 1 Multiword DMA mode 1 is supported. 2 Multiword DMA mode 2 is supported. 8 Multiword DMA mode 0 is currently active. 9 Multiword DMA mode 1 is currently active. 10 Multiword DMA mode 2 is currently active. Bit Word 84 0 SMART error logging is supported. 1 SMART self-test is supported. 2 Media serial number is supported. 3 Media Card Pass Through Command feature set is supported.
6.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read look-ahead and write caching features enabled.
6.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable. S.M.A.R.T. predictability is limited to the attributes the drive can monitor. For more information on S.M.A.R.T.
