Seagate Enterprise Capacity 3.5 HDD v5 Serial ATA Product Manual, Rev. E 5
1.0 Introduction
This manual describes the functional, mechanical and interface specifications for the following:
Seagate® Enterprise Capacity 3.5 HDD v5 Serial ATA model drives:.
These drives provide the following key features:
• 7200 RPM spindle speed.
• Full-track multiple-sector transfer capability without local processor intervention.
• High instantaneous (burst) data-transfer rates (up to 600MB per second).
• Native Command Queuing with command ordering to increase performance in demanding applications.
• Perpendicular recording technology provides the drives with increased areal density.
• PowerChoice™ for selectable power savings
• SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
• State-of-the-art cache and on-the-fly error-correction algorithms.
• Support for S.M.A.R.T. drive monitoring and reporting.
• Supports latching SATA cables and connectors.
• Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability.
• Top Cover Attached motor for excellent vibration tolerance
• Worldwide Name (WWN) capability uniquely identifies the drive.
5xxE models
Standard Standard Power Balance Self-Encrypting (SED) SED (FIPS 140-2)
ST6000NM0115 ST6000NM0215 ST6000NM0175 ST6000NM0275
ST4000NM0115 ST4000NM0245 ST4000NM0225
ST2000NM0125
4KN models
Standard Self-Encrypting (SED) SED (FIPS 140-2)
ST6000NM0125 ST6000NM0185 ST6000NM0265
ST4000NM0085 ST4000NM0055
ST2000NM0105
Note
Seagate recommends validating the configuration with the selected HBA/
RAID controller manufacturer to ensure use of full capacity is supported.
