G0 Scotts Lawn Tractors S1642, S1742, and S2046 OMGX10784 G0 OPERATOR’S MANUAL North American Version Litho in U.S.A.
INTRODUCTION Introduction Thank You for Purchasing a Scotts Product We appreciate having you as a customer and wish you many years of safe and satisfied use of your machine. IMPORTANT: Avoid damage! This text is used to tell the operator of actions or conditions that might result in damage to the machine. NOTE: General information is given throughout the manual that may help the operator in the operation or service of the machine.
PRODUCT IDENTIFICATION Product Identification Record Identification Numbers Scott’s Lawn Tractors S1642, S1742 and S2046 PIN (020001 - ) If you need to contact an Authorized Service Center for information on servicing, always provide the product model and identification numbers. You will need to locate the identification numbers for the product. Record the information in the spaces provided below.
TABLE OF CONTENTS Table of Contents Safety .....................................................................................................................................................................................1 Operating................................................................................................................................................................................8 Replacement Parts ................................................................................
SAFETY • If machine stops going uphill, stop blade and back down slowly. Safety Understanding The Machine Safety Labels • Keep safety devices (guards, shields, and switches) in place and working. • Read operator’s manual. • When leaving machine: –Stop engine –Set park brake –Remove key The machine safety labels shown in this section are placed in important areas on your machine to draw attention to potential safety hazards.
SAFETY DANGER: ROTATING BLADE-THROWN OBJECTS Emission Control System Certification Label NOTE: Tampering with emission controls and components by unauthorized personnel may result in severe fines or penalties. Emission controls and components can only be adjusted by EPA and/or CARB authorized service centers. Contact your John Deere Commercial and Consumer Equipment Retailer concerning emission controls and component questions.
SAFETY Operating Safely Parking Safely 1. Stop machine on a level surface, not on a slope. 2. Disengage mower blades. 3. Lower attachments to the ground. 4. Lock the park brake. 5. Stop the engine. 6. Remove the key. 7. Wait for engine and all moving parts to stop before you leave the operator’s seat. 8. Close fuel shut-off valve, if your machine is equipped. • Read, understand and follow all instructions in the manual and on the machine before starting.
SAFETY Rotating Blades are Dangerous trees, or other objects that may block your vision. HELP PREVENT SERIOUS OR FATAL ACCIDENTS: • Do not let children or an untrained person operate the machine. • Do not carry or let children ride on any attachment or machine even with the blades off. Do not tow children in a cart or trailer. Avoid Tipping • Rotating blades can cut off arms and legs. • Keep hands, feet and clothing away from mower deck when engine is running.
SAFETY Keep Riders Off Driving Safely on Public Roads Avoid personal injury or death resulting from a collision with another vehicle on public roads: • Only allow the operator on the machine. Keep riders off. • Riders on the machine or attachment may be struck by foreign objects or thrown off the machine causing serious injury. • Use safety lights and devices. Slow moving machines when driven on public roads are hard to see, especially at night.
SAFETY machine. Disengage all power and stop the engine. Lock park brake and remove the key. Let machine cool. Tire Safety • Disconnect battery or remove spark plug wire before making any repairs. Explosive separation of a tire and rim parts can cause serious injury or death: • Before servicing the machine, carefully release pressure from any components with stored energy, such as hydraulic components. • Keep all nuts and bolts tightened, especially blade attachment bolts.
SAFETY Handling Waste Product and Chemicals running. • Never fill fuel tank or drain fuel from a machine in an enclosed area. Fill fuel tank outdoors. • Waste products, such as, used oil, fuel, coolant, brake fluid, and batteries, can harm the environment and people: Prevent fires. Clean up spilled fuel immediately. • Do not store machine with fuel in tank in a building where fumes may reach an open flame or spark. • Prevent fire and explosion caused by static electric discharge.
OPERATING E F G H Operating Daily Operating Checklist ❏ Test safety systems. ❏ Check tire pressure. ❏ Check fuel level. ❏ Check engine oil level. ❏ Remove grass and debris from machine. ❏ Clean air intake screen. ❏ Check area below machine for leaks.
OPERATING NOTE: Bottom of wheels should be approximately 6-13 mm (1/4-1/2 in.) from the ground. Adjusting Cutting Height Cutting height can be adjusted from approximately 38 – 100 mm (1-1/2 – 4 in). D C A A B M88571 B 1. Push down on lift lever (A) slightly and hold locking lever (B) down with thumb. 5. Check mower wheel position. Remove bolt (A), bushing (B), washer (C), and nut (D) and move mower wheels to proper hole. 6. Install bolt and tighten with nut to lock wheels in position. 2.
OPERATING NOTE: The difference between blade measurements must not be more than 3 mm (1/8 in). lower left side of mower. 9. Tighten upper adjusting nut. 10.Tighten clamping nut. 11.Measure blade tips again and adjust if necessary. A Adjusting Mower Level (Front-to-Rear) B c CAUTION: Avoid injury! Rotating blades are dangerous. Before adjusting or servicing mower: • Disconnect spark plug wire(s) to prevent engine from starting accidently.
OPERATING service. Perform these tests in a clear open area. Keep bystanders away. C C Testing Mower Engagement Lever Switch B 1. Sit on the seat. B 2. Lock the park brake. 3. Push mower engagement lever (A) forward to engage. 4. Try to start engine. 7. Turn nuts (B) on front draft rods (C) equally until adjustment is correct. Turn nut clockwise to raise front of mower deck or counterclockwise to lower front of mower deck. Result: Engine must not start.
OPERATING c CAUTION: Avoid injury! Rotating blades are dangerous. Children or bystanders may be injured by runover and rotating blades. A Before backing up, carefully check the area around the machine. 3. Look behind the vehicle to be sure there are no bystanders. 4. Begin reverse travel by depressing reverse foot pedal for Automatic transmission or moving gear shift lever to R (reverse) position for Gear transmission. B 3. Pull mower engagement lever (A) back to disengage. 4.
OPERATING Starting Engine c CAUTION: Avoid injury! Engine exhaust fumes contain carbon monoxide and can cause serious illness or death. IMPORTANT: Avoid damage! Starter may be damaged if starter is operated for more than 20 seconds at a time: • Wait two minutes before trying again if engine does not start. Move the vehicle to an outside area before running the engine. D DO NOT run an engine in an enclosed area without adequate ventilation.
OPERATING To travel forward: A B A M96455 Engine is air cooled and needs a large volume of air to keep cool. Keep air intake screen (A) on top of engine clean. 1. Push clutch/brake pedal (A) all the way down to stop machine. Stopping Engine 2. Move shift lever (B) to desired travel speed. 1. Move throttle lever (A) to slow (t) position. Let engine run at low throttle a few seconds. 3. Release clutch/brake pedal slowly. To travel in reverse: C B B A 2. Turn key to stop position (B). 3.
OPERATING To stop travel: 1. Put mower engagement lever in the off position. Push down clutch/brake pedal. 2. Look behind the vehicle to be sure there are no bystanders nearby. Using Travel Controls on Automatic Transmission c CAUTION: Avoid injury! Children or bystanders C may be injured by runover and rotating blades. Before traveling forward or rearward: A • Carefully check the area around the machine. • Disengage the mower before backing up. To travel forward: 3.
OPERATING Using Cruise Control Using The Reverse Implement Option (RIO) c CAUTION: Avoid injury! DO NOT use cruise control when going down hills. Tractor speed will increase. Operate tractor in a large, open area to learn how the cruise control works IMPORTANT: Avoid damage! When cruise control is not in use, hand lever should be returned manually, all the way rearward to OFF position. Otherwise, hand lever will restrict travel of reverse pedal linkage and reverse speed of tractor will be too slow.
OPERATING 3. Release locking lever lock (B) to keep lift lever (A) in position. Using Mower Deck Side Discharge (42-Inch Mower Deck) c CAUTION: Avoid injury! Before you adjust Using Mower mower: STOP engine, remove key, and wait for blades to STOP. 1. Start engine and allow it to idle for two to three minutes. 2. Lower mower to cutting height. Be careful, sharp edges on mower blades. Always wear gloves when handling mower blades.
OPERATING Using Mower Deck Mulch Ready (42-Inch Mower Deck) c CAUTION: Avoid injury! Before you adjust mower: STOP engine, remove key, and wait for blades to STOP. Be careful, sharp edges on mower blades. Always wear gloves when handling mower blades. B A B NOTE: For maximum mulching operation, it may be necessary to change the mower blades, see Servicing Mower Blades in the SERVICE MOWER section.
OPERATING 7. Remove the key. 8. Wait for all moving parts to stop. Transporting Machine on Trailer Be sure trailer has all the necessary lights and signs required by law. IMPORTANT: Avoid damage! Transmission damage may occur if the machine is moved or towed incorrectly: • Move unit by hand only. • Do not use another vehicle to move unit. • Do not tow unit. 1. Drive forward onto heavy-duty trailer. B 2. Lower mower to trailer deck. 3. On Automatic Models: Pull out on free-wheeling lever (B). 4.
OPERATING See your Authorized Service Center for Tire Chains. Mowing Tips The following recommendations will produce the best lawn cut quality and appearance: • Keep mower blades sharp. Dull blades will tear grass; tips of grass will then turn brown. • Cutting grass too short may kill grass and let weeds grow easily. • Adjust cutting height to remove only 1/3 of the grass at a time. • Mow grass often. Short grass clippings will decay quickly. • Mow with engine at full throttle.
REPLACEMENT PARTS Replacement Parts Service Literature ITEM If you would like a copy of the Parts Catalog or Technical Manual for this machine call: Ground Drive Belts: • U.S. & Canada: 1-800-522-7448. • All Other Regions: Your John Deere dealer. PART NUMBER • S1642 GX10851 • S1742 GX10062 • S2046 GX10644 Belts: Parts • 42-Inch Mower Drive Belt M124895 We recommend John Deere quality parts and lubricants, available at your Authorized Service Center.
SERVICE INTERVALS Every 25 Hours Service Intervals Servicing Your Machine IMPORTANT: Avoid damage! Operating in extreme conditions may require more frequent service intervals: • Sharpen/replace blades. • Check and clean air cleaner element, (service more frequently under dusty conditions). • Engine components may become dirty or plugged when operating in extreme heat, dust or other severe conditions.
SERVICE LUBRICATION Lubricating Front Wheel Bearings (On 2046 Model) Service Lubrication Grease IMPORTANT: Avoid damage! Use recommended John Deere greases to avoid component failure and premature wear. A The recommended John Deere greases are effective within an average air temperature range of -29 to 135 degrees C (-20 to 275 degrees F). If operating outside that temperature range, contact your Servicing dealer for a special-use grease.
SERVICE ENGINE Engine Warranty Maintenance Statement The following John Deere oils are preferred: Avoid Fumes c CAUTION: Avoid injury! Engine exhaust fumes contain carbon monoxide and can cause serious illness or death. SAE 10W-30 SAE 10W-40 Maintenance, repair, or replacement of the emission control devices and systems on this engine, which are being done at the customers expense, may be performed by any nonroad engine repair establishment or individual.
SERVICE ENGINE A A 4. Remove dipstick (A). Wipe with clean cloth. 4. Unsnap the dust cap, push and twist to open valve (A). 5. Install dipstick: • S1642: Install dipstick in tube, but DO NOT tighten it. Let dipstick threads rest on top of tube, turn cap counterclockwise until it “clicks” or starts to engage threads. • 5. Drain oil into oil drain pan. Allow oil to drain completely. 6. Remove dipstick. S1742 and S2046: Install and tighten dipstick. 6. Remove dipstick. AD D FU LL B 7.
SERVICE ENGINE Cleaning Air Intake Screen and Engine Fins IMPORTANT: Avoid damage! The engine is aircooled and requires a large amount of air intake when running. Reduced air intake can cause overheating: • Keep air intake screen and cooling fins clean. • Keep covers and screens in place. C 1. Park machine safely. (See Parking Safely in the Safety Section.) 2. Clean air intake screen (A), cooling fins and external surfaces (B), with rag, brush, vacuum or compressed air.
SERVICE ENGINE IMPORTANT: Avoid damage! Dirt and debris can enter the engine through a damaged filter element: • 1. Park machine safely. (See Parking Safely in the Safety Section.) DO NOT wash paper element. • DO NOT attempt to clean paper element by tapping against another object. • Checking and Cleaning Air Cleaner Elements (Model S1742) DO NOT use pressurized air to clean element. c CAUTION: Avoid injury! Touching hot surfaces can burn skin.
SERVICE ENGINE • Put approximately 30 ml. (1 oz.) of clean engine oil onto the precleaner. Squeeze precleaner to distribute the oil evenly. Squeeze out excess oil with a clean cloth. 3. Lift hood. 4. Clean dirt and debris from the air cleaner cover. A IMPORTANT: Avoid damage! Dirt and debris can enter the engine through a damaged filter element: • B DO NOT wash paper element. • DO NOT attempt to clean paper element by tapping against another object. • DO NOT use pressurized air to clean element.
SERVICE ENGINE • Rinse precleaner thoroughly. Squeeze out excess water in a dry cloth until precleaner is completely dry. 3. Remove spark plugs. • Put approximately 30 ml. (1 oz.) of clean engine oil onto the precleaner. Squeeze precleaner to distribute the oil evenly. Squeeze out excess oil with a clean cloth. 5. Inspect spark plugs for: IMPORTANT: Avoid damage! Dirt and debris can enter the engine through a damaged filter element: • • Cracked porcelain. • Pitted or damaged electrodes.
SERVICE ENGINE Replacing Fuel Filter c CAUTION: Avoid injury! Fuel vapors are explosive and flammable: • DO NOT smoke while handling fuel. • Keep fuel away from flames or sparks. • Shut off engine before servicing. • Cool engine before servicing. • Work in a well-ventilated area. • Clean up spilled fuel immediately. NOTE: Change filter when fuel is low. 1. Park machine safely. (See Parking Safely in the Safety Section.) 2. Let engine cool. 3. Put a drain pan under fuel filter. B A A 4.
SERVICE STEERING AND BRAKES Service Steering and Brakes Adjusting Brakes (Gear) c CAUTION: Avoid injury! Rotating blades are E dangerous. Stop engine, remove key, wait for all moving parts to stop before servicing machine. 1. Park machine safely. (See Parking Safely in the Safety Section.) G 2. Check if: F H A 4. From the rear of the tractor, locate the brake disc (E), lock nut (F), and friction puck (G). C 5. Insert a 0.25 mm (0.010 in.) shim gauge (H) between the disc and friction puck.
SERVICE STEERING AND BRAKES does, measure brake components individually. SPECIFICATIONS: • Spring bracket to stop tabs (minimum): 2 mm (0.08 in) • Brake lever travel (maximum): 30° E A Adjusting Brakes (Automatic Foot Control) B C 3. Measure distance from inside of brake rod stop tabs (A) to outside of compression spring bracket (B) (located below foot tread area on left-hand side of transmission). Distance (C) should be 2 – 10 mm (0.08 – 0.40 in).
SERVICE MOWER Service Mower Removing Mower 1. Park machine safely. (See Parking Safely in Safety Section.) Disengage mower blades and wait for all moving parts to stop. E c CAUTION: Avoid injury! Rotating blades are dangerous. Before adjusting or servicing mower: D • Disconnect spark plug wire(s) to prevent engine from starting accidently. F • Always wear gloves when handling mower blades or working near blades. D 2. Put lift lever in highest position. 3. Put wood blocks under each side of mower.
SERVICE MOWER B I J F C D E A 8. Remove spring locking pins and rear draft pins (I), one on each side, from rear draft brackets (J). c CAUTION: Avoid injury! Lift lever is under tension and can snap back when deck is removed. Hold lift lever tightly when releasing from lock (lower) position. 9. Move lift lever to the highest position. Picture Note: Left side of tractor shown. 5. Position the deck so the rear draft arms (A) are between the guide rods (B) and the lift arms (C). 6.
SERVICE MOWER Replacing Mower Drive Belt c CAUTION: Avoid injury! Rotating blades are L dangerous. Before adjusting or servicing mower: • Disconnect spark plug wire(s) to prevent engine from starting accidently. M • Always wear gloves when handling mower blades or working near blades. K Picture Note: Shown from behind L.H. front wheel. 11.Pull down on left-hand side of belt guide (K) and rotate away from engine pulley (L). Install belt (M) through belt guide and onto pulley.
SERVICE MOWER 4. Inspect belt for wear or damage; replace as necessary. 5. Install belt in reverse order of removal. c CAUTION: Avoid injury! Spring is under tension. Do not remove tensioning spring when adjusting mower belt tension. 6. Reinstall belt guard(s) and tighten capscrews securely. 7. Install mower deck and adjust mower belt tension, if necessary. 7. Remove spring locking pin and washer (E) and disconnect tension rod from blade drive arm. 8. Loosen lock nut (F).
SERVICE MOWER IMPORTANT: Avoid damage! ALL brakes MUST be adjusted. There are TWO spindle brakes on the 42Inch deck, and THREE spindle brakes on the 46-Inch deck. 3. Measure distance between blade tip and flat ground surface. 4. Turn blade. Measure distance between other blade tip and flat ground surface. 5. Install new blade, if the difference between the two measurements is more than 3 mm (1/8 in). A Servicing Mower Blades (42-Inch Deck) C B c CAUTION: Avoid injury! Mower blades are D sharp.
SERVICE MOWER 4. Inspect blades; sharpen, balance or replace blades as necessary. E Installing Mower Blades C 1. Lubricate cap screw threads lightly with a general purpose grease or oil. This lubrication is to prevent rusting and seizing. D B A M88112h C 2. Install deflector cup (E) on spindle. 3. Position mower blade (D) with the cutting edge towards the ground onto the mower spindle. D B A 4. Install cupped blade washer (C) with cup side toward the blade. M88112h 5.
SERVICE MOWER A B Keep original bevel (A) when grinding. Blade should have 0.40 mm (1/64 in.) cutting edge (B) or less. Balance blades before installing. Balancing Blades c CAUTION: Avoid injury! Mower blades are sharp. Always wear gloves when handling mower blades or working near blades. 1. Clean blade. 2. Put blade on nail in a vise. Turn blade to horizontal position. 3. Check balance. If blade is not balanced, heavy end of blade will drop. 4. Grind bevel of heavy end. Do not change blade bevel.
SERVICE ELECTRICAL Removing and Installing the Battery Service Electrical WARNING: Battery posts, terminals and related accessories contain lead and lead components, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling. c CAUTION: Avoid injury! The battery produces a flammable and explosive gas. The battery may explode: • DO NOT smoke near battery. • Wear eye protection and gloves.
SERVICE ELECTRICAL positive (+) cable (C) from battery. c CAUTION: Avoid injury! The battery produces 4. Remove black rubber strap (D). 5. Remove battery. a flammable and explosive gas. The battery may explode: Installing: • Do not attempt to jump start a frozen battery. Warm to 16 degrees C (60 degrees F). Install the battery following the removal steps in reverse order. • Do not smoke near battery. • Wear eye protection and gloves. • Keep sparks and flames away.
SERVICE ELECTRICAL Replacing Headlight Bulb A 1. Turn bulb socket (A) 1/4 turn counterclockwise to remove. 2. Replace defective bulb with a new bulb. 3. Insert bulb socket into housing, push in and turn 1/4 turn clockwise to install. Replacing Fuse 1. Park machine safely and lift hood. (See Parking Safely in the Safety Section.) 2. Pull defective fuse(s) (A) out of socket(s). 3. Check metal clip in fuse window and discard fuse if clip is broken. 4. Push new 15 Amp fuse into socket. 5. Lower hood.
SERVICE MISCELLANEOUS Service Miscellaneous Filling Fuel Tank IMPORTANT: Avoid damage! Improper care of machine plastic surfaces can damage that surface: Use regular grade 87 octane unleaded fuel. Add John Deere fuel stabilizer to fuel before using it in your machine to prevent engine damage due to stale fuel. Follow directions on stabilizer container. c CAUTION: Avoid injury! Fuel vapors are • Do not wipe plastic surfaces when they are dry. Dry wiping will result in minor surface scratches.
SERVICE MISCELLANEOUS compound. Do not use power buffer. 4. Apply wax to surface.
TROUBLESHOOTING Troubleshooting Using Troubleshooting Chart If you are experiencing a problem that is not listed in this chart, see your Authorized Service Center for service. When you have checked all the possible causes listed and you are still experiencing the problem, see your Authorized Service Center. Engine IF CHECK Poor Engine Performance Fuel: • Dirt in fuel system or fuel is old. Replace fuel with fresh stabilized fuel. Obtain fuel from another supplier before suspecting machine problems.
TROUBLESHOOTING IF CHECK Engine Hard To Start Dirty air filter. Bad spark plug. Weak or dead battery. Dirty fuel filter. Stale or dirty fuel. Loose or damaged wiring. Carburetor is not adjusted properly or dirty. Engine valves out of adjustment. Below 32°F (0°C) Loss Of Power Cutting too much grass /too fast. Choke adjusted incorrectly. Buildup of grass, leaves and trash under mower. Dirty air filter. Low oil/dirty oil. Faulty spark plug. Dirty fuel filter. Stale or dirty fuel. Water in fuel.
TROUBLESHOOTING IF CHECK Engine Stops When Gear Shift Lever Is Moved To The R (REVERSE) Position and Attachment Is Engaged (Gear) Normal condition. (See Using Reverse Implement Option in the OPERATING section.) Mower IF CHECK Mower Blades Will Not Rotate Obstruction in clutch mechanism, or blades. Worn/damaged mower drive belt. Frozen idler pulley. Frozen blade mandrel. Discharge Chute Plugging Belt worn or installed incorrectly. Grass too wet. Buildup of grass, leaves and trash under mower.
TROUBLESHOOTING IF CHECK Uneven Cut Mower not level. Travel speed too fast. Blades dull, bent or loose. Mower gauge wheels not adjusted correctly. Buildup of grass, leaves, and trash under mower. Bent blade spindle. Grass Tips Are Jagged And Turn Grayish Brown After Mowing Dull mower blades. Bent blades. Front-to-rear blade adjustment not set properly. Mower Stops When Shift Lever Is Moved Rearward and Mower Is Engaged (Hydrostatic) Normal condition.
STORAGE Storage Storing Safety IMPORTANT: Avoid damage! Stale fuel can produce varnish and plug carburetor components and affect engine performance. c CAUTION: Avoid injury! Fuel vapors are explosive and flammable. Engine exhaust fumes contain carbon monoxide and can cause serious illness or death: • Run the engine only long enough to move the machine to or from storage. • Add fuel conditioner or stabilizer to fresh fuel before filling tank. 4. Mix fresh fuel and fuel stabilizer in separate container.
STORAGE specified torque. 6. Lubricate all grease points. 7. Open fuel shut-off valve, if your machine is equipped. 8. Run the engine 5 minutes without the mower or any attachments running to allow oil to be distributed throughout engine. 9. Be sure all shields and guards or deflectors are in place.
SPECIFICATIONS Specifications Model S1642 Engine Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Kohler Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11.9 kW (16 hp) Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS Oil Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes Air Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dry, Replaceable Foam Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS Tire Pressure (Front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 kPa (14 psi) Tire Pressure (Rear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 kPa (10 psi) Mower Deck (42-Inch) Blades-Rotary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ASSEMBLY Assembly Bag of Parts B Description Qty Operator’s Manual 1 Safety Video 1 Key 1 Hardware for Battery: 1 • M8x16 Bolts 2 • M8x16 Nuts 2 A Check and Connect the Battery c CAUTION: Avoid injury! The battery produces a flammable and explosive gas. The battery may explode: • DO NOT smoke near battery. B 3. Pull back the red terminal cover (A) to allow easy access to the positive (+) cable (B) and connect positive (+) cable to battery. • Wear eye protection and gloves.
ASSEMBLY • If tractor/mower deck is being set-up for side discharger or 2-bag bagger DO NOT install mulch cover kit. (See Using Mower Deck Side Discharge OR Using Mower Deck with Optional Equipment in the Operating Mower section.) Check Tire Pressure c CAUTION: Avoid injury! Explosive separation of tire and rim parts is possible when they are serviced incorrectly: • Do not attempt to mount a tire without the proper equipment and experience to perform the job.
WARRANTY Warranty Limited Warranty For New Scotts Brand Products-U.S. Only Manufactured by John Deere (U.S. Only) A. GENERAL PROVISIONS - The warranties described below are provided by John Deere Company (“John Deere”) to the original purchasers of new Scotts Brand Products Manufactured by John Deere. Under these warranties, John Deere will repair or replace, at its option, any covered part which is found to be defective in material or workmanship during the applicable warranty term.
WARRANTY E. LIMITATION OF IMPLIED WARRANTIES AND OTHER REMEDIES SCOTTS BRAND PRODUCTS MANUFACTURED BY JOHN DEERE - TO THE EXTENT PERMITTED BY LAW, NEITHER JOHN DEERE NOR ANY COMPANY AFFILIATED WITH IT MAKES ANY WARRANTIES, REPRESENTATIONS, CONDITIONS OR PROMISES RESPECTING THE SCOTTS BRAND PRODUCTS MANUFACTURED BY JOHN DEERE AND COVERED BY THIS WARRANTY OTHER THAN THOSE LISTED ABOVE.
WARRANTY • Limited Liability Exhaust manifold. Miscellaneous Items Used in Above Systems • Vacuum and temperature switches. • Electronic controls. • Hoses, belts, connectors and assemblies. Since emission related parts may vary slightly from model to model, certain models may not contain all of these parts and certain models may contain functionally equivalent parts.
WARRANTY B. Depreciation or damage caused by lack of reasonable and necessary maintenance or by improper maintenance. C. Transportation, mailing, or service call charges for warranty service. LIMITATION OF IMPLIED WARRANTIES AND PURCHASER’S REMEDIES To the extent permitted by law, neither John Deere nor any company affiliated with it makes any warranties, representations, or promises as to the quality, performance or freedom from defect of the products covered by this warranty.
INDEX Index A Air Cleaner Elements (S1642), Checking and Cleaning 26 Air Cleaner Elements (S1742), Checking and Cleaning 27 Air Cleaner Elements (S2046), Checking and Cleaning 28 Attachment Engagement Lever Switch, Testing ............ 11 Axle Pivot, Lubricating .................................................... 23 B Balancing Blades ............................................................ 39 Battery Set-up for Assembly ........................................... 54 Battery and Terminals, Cleaning .
INDEX Mower Deck Side Discharge - 42-Inch Mower Deck ...... 17 Mower Deck Wheels, Adjusting ........................................ 9 Mower Deck with Optional Equipment - 42-Inch Mower Deck ............................................................................... 18 Mower Drive Belt, Replacing .......................................... 35 Mower Level (Front-to-Rear), Adjusting ......................... 10 Mower Level (Side-to-Side), Adjusting ............................. 9 Mower Lift Lever, Using ..
NOTES Notes Notes
QUALITY STATEMENT Quality Statement Please do not return this tractor to the store where you purchased it. Your Scotts tractor, designed and built by John Deere, is more than just a purchase, it’s an investment in quality. That quality goes beyond our equipment to your dealer’s parts and service support. That’s why John Deere has initiated a process to handle your questions or problems, should they arise. If you have questions or problems with your new tractor, please follow the steps below.
SERVICE RECORD Service Record Record Service Dates Oil Change Oil Filter Change Lubricate Machine Air Cleaner Element Check/Clean Service Record - 64 Fuel Filter Change
