PARTS LIST
Design, prices and specifications subject to change without notice.
SPECIFY MODEL WHEN ORDERING
(See Exploded View on pages 38, 39 & 40)
Part Name Part No. Model
* ✝ Barrel/Receiver Assembly -------- Mark II Models
* ✝ Barrel/Receiver Assembly -------- 22/45 Models
Bolt Only A02101 Mark II - Blued Models
Bolt Only KA02101 Mark II - Stainless Models
Bolt Only AP02101 22/45 - Blued Models
Bolt Only KAP02101 22/45 - Stainless Models
Bolt Assembly, Complete, Not Illustrated A02101-100 Mark II - Blued Models
Bolt Assembly, Complete, Not Illustrated KA02101-100 Mark II - Stainless Models
Bolt Assembly, Complete, Not Illustrated AP02101-100 22/45 - Blued Models
Bolt Assembly, Complete, Not Illustrated KAP02101-100 22/45 - Stainless Models
Bolt Stop Assembly (See Note A on Exploded View) AN-37 Mark II - Blued Models
Bolt Stop Assembly (See Note A on Exploded View) KA-37 Mark II - Stainless Models
Bolt Stop Assembly (See
Note B on Exploded View) AP-37 All 22/45 Models
Bolt Stop Pin A00100 Mark II & 22/45 - Blued Models
Bolt Stop Pin KA00100 Mark II & 22/45 - Stainless Models
Bolt Stop Pin Pivot A02602 Mark II & 22/45 - Blued Models
Bolt Stop Pin Pivot KA02602 Mark II & 22/45 - Stainless Models
Bolt Stop Plunger (See Note A on Exploded View) A04300 Mark II & 22/45 - Blued Models
Bolt Stop Plunger (See
Note A on Exploded View) KA04300 Mark II & 22/45 - Stainless Models
Bolt Stop Plunger Spg. (See Note A on Exploded View) KA04600 All Mark II Models
Bolt Stop Plunger Spg. (See
Note B on Exploded View) KAP04600 All 22/45 Models
Not Illustrated
✝ Contact the Arizona Product Service Department for information regarding Barrel/Receiver Assembly replacement. Be sure to have the
complete serial number and model information before calling [phone].
