Tube Roller User Manual MX-T6-Pro MX-T6-S LCD Digital Tube Roller Classic Tube Roller Please read the User Manual carefully before use, and follow all operating and safety instructions! www.scilogex.
Contents Preface................................................................................. 1 Service................................................................................. 1 Warranty .............................................................................. 1 1. Safety Instructions....................................................... 2 2. Proper Use ................................................................... 3 3. Inspection .....................................................
Tube Roller Please provide the customer care representative with the following information: Preface Welcome to the “Tube Roller User Manual”. Users should read this manual carefully, follow the instructions and procedures, and beware of all the cautions when using this instrument. Service • • • • Serial number ( on the rear panel ) Certification Description of problem ( i.e.
Tube Roller 1. Safety Instructions Warning! • Read the operating instructions carefully before use. • Ensure that only trained staff works with the instrument. Protective ground contact！ • • • If the instrument does not run smoothly, please decrease the motor speed. • Firmly secure the accessories and vessels in place to avoid damage or risk. • Preparation of samples may lead to dangerous flammable. Only process samples that will not react dangerous.
Tube Roller 2. Proper Use 3. Inspection The instrument is designed for mixing sticky substance in schools, laboratories or factories. It can be installed on a variety of impeller, for different viscosity of the medium. This instrument is not suitable for using in residential areas or other constraints mentioned in Chapter 1. Do not use the accessories recommended by the manufacturer, or failure to use the instructions, may be caused unsafe situation. 3.
Tube Roller Items 4. Control and Display 4.1 Control Default settings Mode switch button Mode Shift speed and time display. Speed /timer control knob Set speed and time by rotating speed/timer control knob. Push on/off to start/stop rotating function. Speed/timer light Speed/Timer Green/Red LED display light. Different colors of LED light show the value for speed or time that LCD screen currently displays. Green LED light shows that LCD screen currently displays speed.
Tube Roller LCD display LCD displays the real working state and all setting values. Power I/O Switch ON or OFF the instrument. switch LED light shows green when switch on. Power Power I/O switch Switch ON or OFF the instrument. Table 3 Table 2 4.2 Display Figure 3 Display Figure 3 Items Speed knob control Power light Rotating speed control start/stop rotating function. Set Display when set target value. Err Display in case of error happening.
Tube Roller be automatically halted and an alert will sound. If these operations above are normal, the instrument is ready to operate. If not, the instrument may be damaged during transportation, please contact technical support of manufacturer/supplier. 5. Operation • Place the Rotator in safe and stable surface, ensure the required operating voltage and power supply voltage matched, and the socket must be earthed reliably. • • • • Connect the power cable. Switch ON instrument.
Tube Roller Note: • Electronic device cannot clean with cleanser. • If you require maintenance service, must be cleaned the instrument in advance to avoid pollution of hazardous substances, and to send back into original packing. • If the instrument will not use for a long time, please switch off and place in a dry, clean, room temperature and stable location. 7. Maintenance and Cleaning • Proper maintenance can keep instrument working properly and lengthen its lifetime.
Tube Roller Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Tube Roller 50HZ/60HZ, Cn plug Specifications Items Weight [kg] LCD digital model Classic model 5.1 4.5 Permissible ambient temperature [°C] 5-40 Permissible relative humidity 80% Protection acc.
SCILOGEX, LLC 500 Four Rod Road Suite 122 Berlin, CT 06037 USA Tel: 1-860-828-5289 Fax:1-860-828-5389 E-mail: info@scilogex.com Http://www.scilogex.
