User guide

9
Analog 7” Square (Hotplate) Magnetic Stirrer
Speed range[rpm] 0-1500
Rotary speed display Scale
Speed display accuracy [rpm] 1
Hotplate material Glass ceramic
Dimensions of workplate (mm) 184×184
Dimensions of heating (mm) 176×176
Heating power[W] 1000(Hotplate model)
Temperature range [℃] RT-550(Hotplate model)
Temperature display[℃] Scale(Hotplate model)
The safety temperature range
of the hotplate [℃]
100-580(Hotplate model)
9.Technical data
Voltage [VAC] 100-120/200-240
Frequency [Hz] 50/60
Power [W]
1050(hotplate model)
50
Stirring point position quantity 1
Max. stirring quantity (H
2
O) [l] 20
Max. magnetic bar [L×Ø, mm] 80×10
Motor type Brushless motor
Max. power input of motor [W] 18
Max. power output of motor
[W]
10
