Analog 7’’ Square (Hotplate) Magnetic Stirre User Manual MS7-S Analog 7”Square Plate Magnetic Stirrer MS7-H550-S Analog 7”Square Hotplate Magnetic Stirrer Please read the User Manual carefully before use, and follow all operating and safety instructions! www.scilogex.
Contents Preface…………………………………………………… 2 Service…………………………………………………… 2 Warranty ………………………………………………… 2 1.Safety Instructions …………………………………… 3 2.Sper use ……………………………………………… 4 3.Inspection ……………………………………………… 5 3.1 Receiving Inspection …………………………… 5 3.2 Listing of Items ………………………………… 5 4.Control and Display ………………………………… 5 4.1 Control Elements ……………………………… 5 5.Trial Run ……………………………………………… 6 6.Faults ………………………………………………… 7 7.Maintenance and Cleaning …………………………… 7 8.Associated Standards and Regulations ……………… 8 9.
Analog 7” Square (Hotplate) Magnetic Stirrer Welcome to the“Analog 7” Square (Hotplate) Magnetic Stirrer”. Users should read this Manual carefully, follow the instructions and procedures, and be aware of all the cautions when using this instrument. Please provide the customer care representative with the following information： • Serial number（on the rear panel） • Description of problem (i.e.
Analog 7” Square (Hotplate) Magnetic Stirrer 1.Safety Instructions • Warning! • Read the operating instructions carefully before use. • Ensure that only trained staff works with the instrument. • • Risk of burn! • Caution when touch the housing parts and the hotplate which can reach temperature of 550°C. • Pay attention to the residual heat af ter switching off. • • Protective ground contact! • Make sure that socket must be grounded (protective ground contact) before use.
Analog 7” Square (Hotplate) Magnetic Stirrer • • • • • • excessively high temperatures to be measured especially in with poor conductivity. The tip of the measuring sensor must be at least 5 mm from vessel bottom; a distance of 10 mm is ideal. The instrument can only be disconnected from the main power supply by pulling out the main or the connector plug The voltage stated on the label must correspond to the main power supply. Ensure that the main power supply cable does not touch the hotplate.
Analog 7” Square (Hotplate) Magnetic Stirrer 3.Inspection 4.Control 3.1 Receiving Inspection 4.1 Control elements Unpack the equipment carefully and check for any damages which may have arisen during transport. Please contact manufacturer/supplier for technical support. Note: If there is any apparent damage to the system, please do not plug it into the power line. 3.
Analog 7” Square (Hotplate) Magnetic Stirrer Items Default settings Speed control Knob Stir Set the rated rotary speed. The stirring function is switched ON or OFF by pushing the knob. 5.Trial run • Make sure the required operating voltage and power supply voltage match. • Ensure the socket must be properly grounded. • Plug in the power cable，ensure the power is on and Set the rated temperature. The Temperature control knob heating function is switched Heat (Hotplate) ON or OFF by pushing the knob.
Analog 7” Square (Hotplate) Magnetic Stirrer 6.Faults 7.Maintenance and Cleaning • Instruments can not be power ON • Proper maintenance can keep instruments working • • Do not spray cleanser into the instrument when cleaning. • Unplug the power line when cleaning. • Only use recommended cleansers: • • • - Check whether the power cable is plugged in. - Check whether the fuse is broken or loose.
Analog 7” Square (Hotplate) Magnetic Stirrer • Send in the case of service the instrument back in the 8.Associated regulations • Construction in accordance with the following safety standards: packaging carton. Storage packing is not sufficient for the back dispatch. Use additionally a suitable transportation packing. The enamel makes the hotplate easier to care for and more resistant to acids and bases.
Analog 7” Square (Hotplate) Magnetic Stirrer 9.Technical data Speed range[rpm] 0-1500 Voltage [VAC] 100-120/200-240 Rotary speed display Scale Frequency [Hz] 50/60 Speed display accuracy [rpm] 1 Power [W] 1050(hotplate model) 50 Hotplate material Glass ceramic Stirring point position quantity 1 Dimensions of workplate (mm) 184×184 Max. stirring quantity (H2O) [l] 20 Dimensions of heating (mm) 176×176 Max.
Analog 7” Square (Hotplate) Magnetic Stirrer Dimensions (mm) 215×360×112 Weight [kg] 5.3 10.Ordering information Cat No. MS7-H550-S Analog 7”Square Hotplate 813221009999 Magnetic Stirrer, glass ceramics hotplate, USA plug, 110V/50Hz/60Hz Permitted ambient temperature [℃] 5-40 Permitted relative humidity Descriptions 80% Stection class acc.
Analog 7” Square (Hotplate) Magnetic Stirrer MS7-S Analog 7” Square Plate Magnetic 813211019999 Stirrer, glass ceramics plate, Cn plug, 220V/50Hz/60Hz MS7-S Analog 7” Square Plate Magnetic 813211029999 Stirrer, glass ceramics plate, Euro plug, 220V/50Hz/60Hz MS7-S Analog 7”Square Plate Magnetic 813211039999 Stirrer, glass ceramics plate, UK plug, 220V/50Hz/60Hz MS135.2 Red quarter pie, 11 holes, 4 ml reaction vessel, Ø15.2mm, 20mm depth 18900003 MS135.
SCILOGEX, LLC 500 Four Rod Road Suite 122 Berlin, CT 06037 USA Tel：1- (860) 828-5614 Fax：1- (860) 828-5389 E-mail: info@scilogex.com Website：Http://www.scilogex.
