Model 700 Microarray Oven — USER MANUAL
Version 2.1, February 2011 [phone], [e-mail]
11
V. TROUBLESHOOTING
Symptom Cause Solution
Rotator does not turn
after closing door
Rotator control is in the off
position
Turn on rotator
Door does not shut or
is difficult to open
Latch is improperly
adjusted
Adjust threaded
rod on inside of
latch
Temperature is erratic Thermal controller is
defective
Replace controller
VI. SPECIFICATIONS
Electrical (Oven Unit)
Cat. #1070-00-1 115V AC; 50/60 Hz; 350 W
Cat. #1070-00-2 230V AC; 50/60 Hz; 350 W
Dimensions
Interior Chamber 14 W x 14 D x 14 H inches
36 W x 36 D x 36 H cm
Exterior 18 W x 17 D x 22 H inches
45 W x 40 D x 56 H cm
Weight
Net 70 lbs (32kg)
Gross 75 lbs (34kg) Includes shipping carton
Performance and Controls
Temperature Range Ambient +5°C to 99°C
Temperature Control ± 0.1°C
Heat up Time 3°C per minute
Temperature Controller Digital PID, single loop
Temperature Display Actual / Set Dual LED
Rotation Speed Up to 20 RPM
Chamber Stainless Steel
Digital Thermometer Output Thermocouple
VII. ROTATORS AND ACCESSORIES
Cat. # Description UOM
1070-20-0 Rotator for Agilent SureHyb and Original Version
Hybridization Chamber. Holds 20 chambers
Each
1052-23-0 General Purpose Rotator Each
1052-24-0 Loading Stand for General Purpose Rotator Each
1040-21-0 Removable Rocking Platform Each
1040-21-1 Rotator for 10 large/20 small hybridization tubes Each
1040-01-0 Hybridization tube, 35x300 mm with screw cap Each
1040-02-0 Hybridization tube, 35x150 mm with screw cap Each
1051-52-0
Digital thermometer with NIST certificate of calibration
Each

