Specifications for SL Laboratory Balances:
Model SL400 SL600 SL1000 SL2000 SL3000 SL5000 SL6000 SL3100D SL5200D
Weighing Mode Single Range Dual Range
(Floating T
Capacity 400g 600g 1000g 2000g 3000g 5000g 6000g 1000g 2000g
3000g 5000g
Readability 0.01g 0.01g
Tare Range 0-400g 0-600g 0-1000g 0-2000g 0-3000g 0-5000g 0-6000g 0-3000g 0-5000g
0-3000g 0-5000g
Repeatability 0.01g 0.01g
(Standard Deviation) 0.05g
Linearity ±0.015g ±0.015g
±0.05g
Stabilization Time User Selectable
Weighing Speed Adaptive
Display Update Interval 300 ms
Data Interface RS-232 bidirectional interface is standard. Baud rates are 300, 600, 1200, 2400, 4800, 9600 and 19,200
Pan Size Circular 4.5 inch diameter Circular 6.5 inch diameter
Operating Temperature 5°C to 40°C
Relative Humidity 80 % for temperature up to 31°C decreasing linearly to 50 % at 40°C
Power Supply 115 Volts/60 Hz ± 10 %
230 Volts/50 Hz or 60 Hz ± 10 %
Windscreen Optional
Calibration Weight 400g 600g 1000g 2000g 3000g 5000g 6000g 3000g 5000g
200g 500g 500g 1000g 2000g 2000g 5000g 2000g 2000g
Housing (WxDxH) 7.5" x 11.25" x 3.25"
Weight ~ 8.5 lbs
are™)
0.1g
