Specifications for SA Analytical Balances:
Model SA 80 SA 120 SA 210 SA 310 SA 410 SA 510 SA 210D SA 525D
Weighing Mode Single Range Dual Range
(Floating Tare™)
Capacity 80g 120g 210g 310g 410g 510g 100g 250g
200g 500g
Readability .0001g .0001g
.001g
Tare Range 0-80g 0-120g 0-210g 0-310g 0-410g 0-510g 0-200g 0-500g
0-200g 0-500g
Repeatability .0001g .0001g .0001g .00015g .00015g .0002g .0001g .00015g
(Standard Deviation) .0005g .0005g
Linearity ±.0002g ±.0002g
±.0005g
Stabilization Time User Selectable
Weighing Speed Adaptive
Display Update Interval 200ms
Data Interface RS-232 bidirectional interface is standard. Baud rates are 300, 600, 1200, 2400, 4800, 9600 and 19,200.
Pan Size Circular 3.5 inch diameter
Operating Temperature 5°C to 40°C
Relative Humidity 80 % for temperatures up to 31°C decreasing linearly to 50 % at 40°C
Power Supply 115 Volts/60 Hz ± 10 %
230 Volts/50Hz or 60 Hz ± 10 %
Windscreen 7.5W x 8.25D x 9.5H
Calibration Weight 80g 100g 200g 300g 400g 500g 200g 500g
50g 50g 100g 200g 200g 100g 200g
Housing (WxDxH) 7.5" x 11.25" x 3.25"
Weight ~ 13.8 lbs
