Introduction and Specifications
Specifications
1.4
Specifications
Operating Temperature Range
–40° to +85°C (–40° to +185°F)
5 to 95% humidity (noncondensing)
Electromagnetic Compatibility
Electrostatic
Discharge
Immunity: IEC 60255-22-2: 1996
[EN 60255-22-2: 1997]
IEC 61000-4-2: 1995
[EN 61000-4-2: 1995
+ A1:1999
+ A2:2001]
IEEE C37.90.3: 2001
Severity Level: 2, 4, 6,
8 kV contact
discharge; 2, 4, 8,
15 kV air discharge
Radio Frequency
Interference
Immunity: IEC 61000-4-3: 2002
[EN 61000-4-3: 2002]
IEC 60255-22-3: 2000
[EN 60255-22-3: 2001]
Severity Level: 10 V/m
IEEE C37.90.2: 2004
Severity Level: 35 V/m
Power Frequency
Magnetic Field
Immunity: IEC 61000-4-8: 2001
[EN 61000-4-8: 1994
+ A1:2001]
Severity Level:
100 A/m (60 Sec),
1000 A/m (3 Sec),
Level 5
Pulse Magnetic
Field Immunity: IEC 61000-4-9: 1993:
2001
[EN 61000-4-9: 1994
+ A1:2001]
Severity Level:
1000 A/m, Level 5
Damped Oscillatory
Magnetic Field
Immunity: IEC 61000-4-10: 2001
[EN 61000-4-10: 1994
+ A1:2001]
Severity Level:
100 A/m, Level 5
Radiated Radio
Frequency:
(900 MHz and
1.89 GHz
with modulation): ENV 50204: 1995,
10 V/m
Emissions: FCC Part 15, Class B
Environmental
Cold IEC 60068-2-1: 1990
+ A1:1993 + A2:1994
[EN 60068-2-1:1993
+ A2:1995]
Temperature
Shock on
SEL-8310: MIL-STD-810F
Method 503.4
–40°C (–40°F) and +70°C (158°F) with
temperature stabilized inside the unit.
Dry Heat: IEC 60068-2-2: 1974
+ A1:1993 + A2:1994
[EN 60068-2-2: 1993
+ A1:1995]
Damp Heat,
Cyclic: IEC 60068-2-30: 1980
+ A1:1985
[EN 60068-2-30:1999]
Vibration
Resistance: IEC 60255-21-1: 1988
[EN 60255-21-1: 1996
+ A1:1996]
Vibration
Endurance: Severity Class 1
Vibration
Response: Severity Class 2
Shock Resistance: IEC 60255-21-2: 1988
[EN 60255-21-2: 1996
+ A1:1996]
Bump Test: Severity Class 1
Shock Withstand: Severity Class 1
Shock Response: Severity Class 2
