SEL-8310 Remote Fault Reader Operation
DIP Switch Settings
3.3
The four audio modes are described briefly below. Refer to Audio Indication, for
specific audio indications corresponding to each setting.
Silent Mode—Annunciates Process Status and Button Press information only.
Summary Mode—Annunciates Process Status, Button Press, and FCI Status
Summary information only.
Morse Code Mode—Provides all audio indications. FCI Status Summary
information is followed by FCI Detail information annunciated in Morse
Code.
Row/Column Mode—Provides all audio indications. FCI Status Summary
information is followed by FCI Detail information annunciated in
Row/Column Mode.
All audio indications will be annunciated at the current volume control setting, with the
exception of HMI Adjust Mode indications.
You can configure the SEL-8310 for single frequency operation to allow two
SEL-8310 units to operate within the same area simultaneously, with each unit on a
different frequency. Ta ble 3.2 shows the DIP switch settings that enable this
functionality.
When DIP Switch 3 is in the ON position, DIP Switch 4 determines the single
frequency to be used. If DIP Switch 3 is in the OFF position, then DIP Switch 4 has no
effect. If using two SEL-8310 units in the same area, both units should have DIP
Switch 3 set to ON and one of the units should have DIP Switch 4 set to ON.
Table 3.1 Four Audio Modes Selectable With the DIP Switch Block
Audio Mode DIP Switch 1 DIP Switch 2
Silent Mode ON ON
Summary Mode ON OFF
Morse Code Mode OFF ON
Row/Column Mode OFF OFF
Table 3.2 DIP Switch Settings
Position of
Switch
DIP Switch 3 Functionality
DIP Switch 4
Functionality
OFF Single-Frequency Operation Disabled Use Base Frequency
ON Single-Frequency Operation Enabled Use Offset Frequency
