Product Specifications

Conext
TM
Conguration Tool
Simplify the system
configuration and reduce
installation time.
Product at a glance
The Conext Configuration Tool is used by system installers and its
purpose is to simplify the task of system configuration and reduce
installation time. It is a PC-based software tool that works on systems that
include the Conext™ XW, Conext™ XW+, Conext™ SW and peripherals.
The Conext Configuration Tool is not meant to replace the Conext™
System Control Panel, Conext™ ComBox or any other monitoring
devices. Those devices may still be required to monitor the Conext
System and components.
The Configuration Tool allows the installer to perform the following
functions:
• System and device configuration
• System logging
• Firmware upgrades
• Saving and Restoring configurations
• Single inverter or multi-cluster configuration
• Parameter adjustment, Voltage and Frequency
• Compatible OS : Windows 7 , 8 and 10
Part number : 865 - 1155 - 01
The Configuration Tool should not be used
with the Conext™ ComBox connected to
the Xanbus network and when performing
firmware upgrades. Disconnect the Conext™
ComBox from the Xanbus network when the
Configuration Tool is in use.
Conext Conguration Tool Software Interface
