Assembling TSX Momentum Components
94
870 USE 101 00 V.3
Disassembling a Module with an Option Adapter, Continued
Procedure:
Disassembling
an Option
Adapter and M1
Processor
Follow the steps in the table below to remove the Option Adapter from the M1
processor.
Step Action
1 Use a screwdriver to push the clips on both sides of the adapter inward.
2 Lift off the adapter.
