Configuring an M1 CPU with Concept
870 USE 101 00 V.3 335
Accessing and Editing the I/O Map, Continued
Editing the Local
I/O Map
From the I/O Map dialog box, perform the steps in the following table to edit the
local I/O Map:
Continued on next page
Step Action
1 Click the Edit... button at the end of the row.
Result: The Local Momentum I/O dialog box appears.
2 Click the button under Module and select your local I/O base from the dropdown
menu.
