Configuring an M1 CPU with Concept
332
870 USE 101 00 V.3
Completing the I/O Configuration, Continued
Cut and Paste To move a row within the configuration list, follow the directions for copying, only
use the Cut button instead of the Copy button.
Delete To delete a row from the configuration list, select the row by clicking on the row
number at the far left. Then click the Delete button.
Sort To sort the I/O configuration list, select a column by clicking on the column heading
(ie. Read Ref Master). Then click the Sort button.
Continued on next page
