Configuring an M1 CPU with Concept
870 USE 101 00 V.3 291
Selecting an M1 Processor Adapter, Continued
Procedure,
Continued
Step Action
5 Choose your PLC type from the CPU/Executive menu.
Result: The remaining fields are filled with corresponding values.
6 Click the <OK> button.
Result: Your PLC type and default configuration parameters are displayed in the
PLC Configuration screen.
