Configuring an M1 CPU with Concept
870 USE 101 00 V.3 289
Selecting an M1 Processor Adapter, Continued
Procedure,
Continued
Continued on next page
Step Action
3 From the Configure menu, select PLC Type OR double-click on the Type field in
the dialog box.
Result: The PLC Selection dialog box appears. The default selection is Quantum.
