Configuring an M1 CPU with Concept
286
870 USE 101 00 V.3
Section 12.1
Configuring the Processor Adapter
Overview
Purpose This section describes how to configure a TSX Momentum M1 Processor Adapter
using Concept 2.2.
In This Section This section contains the following topics:
For This Topic... See Page...
Selecting an M1 Processor Adapter 287
Default Configuration Parameters 292
Changing the Range of Discrete and Register References 295
Changing the Size of the Full Logic Area 297
Understanding the Number of Segments 298
Changing the Size of the I/O Map 299
Establishing Configuration Extension Memory for Peer Cop 301
