Using Peer Cop with Modsoft
870 USE 101 00 V.3 243
Defining the Link and Accessing a Node, Continued
Procedure,
Continued
Next Step Confirming the Peer Cop summary information.
Step Action
3 Push <Enter>.
Result: The Add Node popup disappears, and the Peer Cop summary information
values are set as follows:
