Using Peer Cop with Modsoft
870 USE 101 00 V.3 235
Accessing the Peer Cop Configuration Extension Screen
Introduction Before you can access the Peer Cop Configuration Extension screen, you must
have specified enough extension memory to support your Peer Cop database.
This section describes how to access the screen and, if necessary, adjust the
amount of configuration extension memory.
Accessing the
Screen
Starting from the Configuration Overview screen, select Peer Cop from the Cfg Ext
menu.
Adjusting
Extension
Memory
Extension memory is specified as a number of 16-bit words. That number is
entered in the ExtSize field of the Configuration Overview screen. Once an
adequate number of words has been specified there, Peer Cop will be enabled in
the Cfg Ext menu.
Extension
Memory Size
The minimum Peer Cop memory requirement is 20 words. The maximum is 1366
words.
Continued on next page
Note: If Peer Cop is disabled in the pulldown list, you will need to specify
enough extension memory to support your Peer Cop database before you
can continue.
