Configuring an M1 CPU with Modsoft
220
870 USE 101 00 V.3
Accessing and Editing the I/O Map, Continued
Editing the Local
I/O Map
Continued on next page
Step Action
3 Assign the appropriate state RAM reference(s) to the unit.
Example: In the screen below, one 3
x
register (300001) has been assigned for
the input points and one 4
x
register (400001) has been assigned for the output
points:
4 Press <Esc> to return to the Configuration Overview editor.
