Overview of TSX Momentum M1 Processor Adapters
870 USE 101 00 V3 21
Front Panel illustration
Introduction This section provides a illustration of a typical M1 Processor Adapter.
Illustration A typical Processor Adapter is shown in the following illustration:
Label Description
1 Standard port connector
2 Optional second port connector
3 LED indicators
