Configuring an M1 CPU with Modsoft
208
870 USE 101 00 V.3
Section 8.3
Modifying Communication Port Parameters
Overview
Purpose The communication parameters on the Modbus ports are set at the factory. This
section describes how to access the Port editor and how to edit the default
parameters.
In This Section This section contains the following topics.
For This Topic... See Page...
Accessing the Port Editor Screen 209
Parameters Which Should Not Be Changed 210
Changing the Mode and Data Bits 211
Changing Parity 213
Changing the Baud Rate 214
Changing the Modbus Address 215
Changing the Delay 216
Changing the Protocol on Modbus Port 2 217
