Setting the Time
Overview Once you have reserved a block of registers for the time-of-day clock, you have to
set the correct time. Modsoft offers two ways to do this:
l using the Set Hardware Clock dialogue
l setting the register bits individually
Option 1 You must be online or in combined mode to access the Set Hardware Clock
dialogue.
Continued on next page
Note: The time-of-day clock complies with guidelines for the year 2000.
Step Action
1 From the PlcOps menu, select Set Hardware Clock.
Result: The Set Hardware Clock dialogue appears.
2 You may set the time directly or copy the current time setting from your
programming panel.
To set the time directly, proceed to step 3.
To copy the setting from your programming panel, proceed to step 4.
3 The time setting for your programming panel is displayed on the left. The
controller time setting is displayed on the right. The time is expressed as
hh:mm:ss. The date is expressed as mm-dd-yy.
To modify the settings, type a new value in the date or time field for the
controller.
To confirm the default settings or your modified settings, press <Enter>.
4 To copy the current time setting from your programming panel, type Y in
response to the question:
Write PANEL clock data to PLC? (Y/N).
Then press <Enter>.
