Using the Modbus Ports
104
870 USE 101 00 V.3
Modbus Port 1, Continued
Port Parameters Modbus Port 1 supports the following communication parameters.
Continued on next page
Baud 50 1800
75 2000
110 2400
134 3600
150 4800
300 7200
600 9600
1200 19,200
Parity EVEN
ODD
NONE
Mode/Data Bits 7-bit ASCII
8-bit RTU
Stop Bit 1
Modbus Address In the range 1 ... 247
