Operating instructions

BASCJ_EN
V01 | 02.2011
9
www.schaerer.comProduct description
Options and optional accessories
Technical data
Example Option Description
Additional cooling unit External cooling unit for machines with Milk
Smart.
Capacity: 2 l
Add-on bean hopper Additional mountable bean hopper for grea-
ter bean capacity.
Capacity: 400 g
Water filter for internal drinking water tank The water filter can be installed in the internal
drinking water tank.
Capacity: 200 l
For detailed information, please contact your sales partner.
Nominal power * 1700 – 2300 W
Operating temperature Steam boiler Hot water boiler
Minimum operating temperature (T min.): 130°C 86°C
Maximum operating temperature (T max.) 130°C 102°C
Overpressure Steam boiler Hot water boiler
Working overpressure 2.5 bar 16 bar
Permissible working overpressure (p max): 16 bar 16 bar
Test overpressure 24 bar 24 bar
Water tank capacity 2.2 l
Bean hopper capacity 250 g
Grounds container capacity 15 – 20 coffee ground cakes
External dimensions
Width 305 mm
Height 400 mm
Depth 443 mm
Empty weight 15 kg
