Installation manual

Installation and servicing instructions strictly reserved for qualified gas installers
13
Legend
1 Flue outlet
2 Main heat exchanger
3 Burner
4 Ignition and control electrode
5 Fan
6 Gas control valve
7 DHW storage vessel
8 Condensate drain
9 Overheat safety thermostat
10 Temperature sensor for DHW storage
vessel
11 Expansion vessel
12 Heating return thermistor
13 Heating flow thermistor
14 Ignition module
15 Heating Pump
16 Water pressure sensor
17 Domestic plate to plate heat exchanger
18 Three way valve
19 Domestic expansion vessel
20 Drain cock
21 Flow switch
22 Heating discharge safety valve
23 DHW temperature sensor
24 DHW discharge safety valve
25 Heating isolating valve
26 Filter on cold water inlet
27 Filling system
28 Filter on heating circuit
29 Heating isolating valve
30 Domestic cold water isolating valve
31 Heating isolating valve
32 Gas isolating valve
33 DHW pump
34 Storage anode protection
35 Non return valve
36 Temperature / pressure relief valve
37 Tapping (plug connection) for the
recirculation loop
38 Pressure reducing valve and check
valve
A Heating return
B Cold water inlet
C Heating flow
D Domestic hot water outlet
D1 Discharge from HTG safety valves
D2 Discharge from temp / press and
expansion valve (to tundish)
E Gas
F Cold water supply
3 Appliance location
This appliance is not suitable for
outdoor installation.
This appliance may be installed in any
room, although particular attention is
drawn to the installation of an appliance
in a room containing a bath or shower
where reference must be made to the
relevant requirements. In GB this is the
current I.E.E. WIRING REGULA
TIONS
and BUILDING REGULATIONS.
In IE reference should be made to the
current edition of I.S.813 «Domestic
Gas Installations» and the current ETCI
rules.
•
•
•
Make sure you keep an appropriate
distance between the sides of the
appliance to ensure total accessibility
for servicing.
The appliance must be mounted on a
flat wall, which is suffi
ciently robust to
take its weight.
The appliance is room sealed, so when
it is installed in a room or space, a
permanent air vent is not required.
Do not install the appliance above
another appliance that could damage
it (for example, above a cooker that
might emit steam or grease) or in a
room, which has a lot of dust in the
atmosphere which is corrosive.
•
•
•
•
