Chapter 6 Upgrading Device Firmware
ETC2002 Network Communicator 53
Baud Rate: 19200
New: 115200
5. Print 115200 and press Enter. Now the Flash Loader communicates at
115200 baud.
6. To accommodate HyperTerminal to the new baud rate, select Open
from the File menu, click Yes in response to the HyperTerminal
question, and then double-click on your “115200” session file.
7. Print p and press Enter. The following text appears:
p
Programming Flash
-----------------
Send HEX-32 file as a text file.
NB: Use standard XON/XOFF flow control.
NB: Ensure that LF is not stripped at the end of lines.
To abort downloading, press Esc.
0 characters received...
8. From the Transfer menu, select Send Text File, and then select “All files
(*.*)” in the “File of type” box. On the file pane, point to your new
firmware image HEX file and click Open. HyperTerminal starts the file
transfer.
When downloading is complete, the following message appears:
Downloading complete. 924836 characters received.
336260 bytes written into Flash.
>
If downloading fails, repeat steps 7 and 8 again.
