DISPLAY
Description
Reg 1 Imp MAX
0.008 kW
Total Import Max. DMD active power data
(Reg1 for TOU/Max. DMD actve power,
Reg2 for TOU/Max. DMD reactve power
predefined TOU/Register factory setup,
can be changed by user, see Configuring
Billing/Tariff Registers and Configuring the
Daily Tariff Schedule in Chapter 5)
Reg 1/T1 Imp MAX
0.008 kW
Tariff 1 Import max. active power dmd
data.
Reg 1/T2 Imp MAX
0.008 kW
Tariff 2 Import max. active power dmd
data
Reg 1/T3 Imp MAX
0.002 kW
Tariff 3 Import max. active power dmd
data
Reg 2 Imp MAX
0.003 kvar
Total Import Max. DMD reactive power
data
Reg 2/T1 Imp MAX
0.003 kvar
Tariff 1 Import max. reactive power dmd
data.
Reg 2/T2 Imp MAX
0.003 kvar
Tariff 2 Import max. reactive power dmd
data.
Reg 2/T3 Imp MAX
0.001 kvar
Tariff 3 Import max. reactive power dmd
data.
Reg 3 Imp MAX
0 kVA
Total Import Max. DMD apparent power
data
Reg 3/T1 Imp MAX
0 kVA
Tariff 1 Import max. apparent power dmd
data.
Reg 3/T2 Imp MAX
0 kVA
Tariff 2 Import max. apparent power dmd
data.
Reg 3/T3 Imp MAX
0 kVA
Tariff 3 Import max. apparent power dmd
data.
