User Manual

Chapter 1 General I N F O R M A T I O N
EM13x Series SMART MULTIFUNCTION METER 13
and pulse operations, failsafe operation for alarm notifications;
programmable pulse width; direct remote relay control through
communications; 1-cycle update time.
12DI/4RO Module
12 dry contact digital inputs (DI) for monitoring external contacts
and receiving pulses from energy, water, and gas meters;
Programmable de-bounce time; 1-ms scan time.
4 electro-mechanical relay outputs (RO) for alarms and controls,
and for output energy pulses; unlatched, latched and pulse
operations, failsafe operation for alarm notifications;
programmable pulse width; direct remote relay control through
communications; 1-cycle update time.
Analog Output
The EM13X Series analog output (AO) expansion module provides:
4 optically isolated analog outputs with an internal power supply;
Options for 0-20mA, 4-20mA, 0-1mA, and 1mA output; 1-cycle
update time.
Additional Communication Port COM2
A second COM2 communication port can be ordered as an expansion
module. COM2 options available:
Ethernet 10/100BaseT port; MODBUS/TCP, DNP3/TCP or IEC
60870-5-104 communications protocols
PROFIBUS DP port
RS-232/RS-422/RS-485 port; MODBUS RTU, DNP3 or IEC 60870-
5-101, and SATEC ASCII communication protocols;
GPRS communications port; MODBUS/TCP protocol
RF communication; MODBUS RTU protocol
1.3 Customized Options
Presentation of data on the front display and via communications can
be customized to best suit the user application.
Device Resolution
A low or high-resolution option can be selected for the presentation of
voltage, current, and power for use in high and low power applications.
Display Options
Different display options are available for customization to be used in
dark or non-safe locations, or in places that are hardly accessible for
observation.
1.4 Measured Parameters
Table 1: Measured and Displayed Parameters
Display
Comm.
Analog
Pulse
Alarm
