User's Manual

Page 3 of 7
LPA-24G-1 Connectors
J3 PROGRAMMING CONNECTOR
PIN 1*
TDO/TDI
PIN 2
3.3 VOLTS
PIN 3
TDI
PIN 4
3.3 VOLTS
PIN 5
S2 DRV (TMS)
PIN 6
1.8 VOLTS
PIN 7
TCLK
PIN 8
TEST
PIN 9
GROUND
PIN 10
GROUND
PIN 11
RST
PIN 12
TXD
PIN 13
SHIELD
PIN 14
RXD
* PIN 1 IS THE SQUARE PAD.
J4 GEARBOX CONNECTOR
PIN 1*
MOT SEC 1 1.8 VOLTS
PIN 2
MOT SEC 2
PIN 3
MOT MIN 1 1.8 VOLTS
PIN 4
MOT MIN 2
PIN 5
GRBX SEL A
PIN 6
GRBX SEL B
PIN 7
PWR DET
PIN 8
S1
PIN 9
GROUND
PIN 10
S2
PIN 11
3.3 VOLTS
PIN 12
GRBX DET
PIN 13
1.8 VOLTS
PIN 14
GROUND
* PIN 1 IS THE SQUARE PAD.
J3 PROGRAMMING
J4 POWER & DATA
