Operation Manual

Chapter 4 Settings — [PICTURE] menu
86 - ENGLISH
Note
f DICOM is an abbreviation of “Digital Imaging and COmmunication in Medicine” and is a standard for medical imaging devices. Although the
DICOM name is used, the projector is not a medical device, and should not be used for purposes such as diagnosis of display images.
Changing the name of [USER1] or [USER2]
1) Press as to select [GAMMA].
2) Press qw or the <ENTER> button.
f The [GAMMA] individual adjustment screen is displayed.
3) Press qw to select [USER1] or [USER2].
4) Press the <ENTER> button.
f The [GAMMA] screen is displayed.
5) Press the <ENTER> button.
f The [GAMMA NAME CHANGE] screen is displayed.
6) Press asqw to select the text, and press the <ENTER> button to enter the text.
7) Press asqw to select [OK], and press the <ENTER> button.
f The selected gamma name is changed.
Note
f When a name is changed, display of [USER1], [USER2] is also changed.
[SYSTEM DAYLIGHT VIEW]
You can correct the image to the optimal vividness even if it is projected under a bright light.
1) Press as to select [SYSTEM DAYLIGHT VIEW].
2) Press qw or the <ENTER> button.
f The [SYSTEM DAYLIGHT VIEW] individual adjustment screen is displayed.
3) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] No correction.
[1] - [6] Corrects the vividness of the image. The larger the value, the stronger the correction.
[SHARPNESS]
You can adjust the sharpness of the projected image.
1) Press as to select [SHARPNESS].
2) Press qw or the <ENTER> button.
f The [SHARPNESS] individual adjustment screen is displayed.
3) Press qw to adjust the level.
Operation Adjustment Range of adjustment
Press w.
Contours become sharper.
0 - +15
Press q.
Contours become softer.
Note
f If you press w while the adjustment value is [+15], the value will become [0]. If you press q while the adjustment value is [0], the value will
become [+15].
