Operation Manual

Chapter 4 Settings — [PICTURE] menu
84 - ENGLISH
[USER1]
Adjusts white balance as desired. Refer to “Adjusting desired white balance” (x page 84) for
details.
[USER2]
[3200K] - [9300K] Allows you to set in increments of 100 K. Select so that images become natural.
Note
f When [PICTURE MODE] (x page 82) is set to [USER] or [DICOM SIM.], [DEFAULT] cannot be selected.
f When [COLOR MATCHING] (x page 107) adjustment is set to other than [OFF], [COLOR TEMPERATURE] is xed to [USER1].
f The color temperature numerical values are guidelines.
Adjusting desired white balance
1) Press as to select [COLOR TEMPERATURE].
2) Press qw or the <ENTER> button.
f The [COLOR TEMPERATURE] individual adjustment screen is displayed.
3) Press qw to select [USER1] or [USER2].
4) Press the <ENTER> button.
f The [COLOR TEMPERATURE] screen is displayed.
5) Press as to select [WHITE BALANCE].
6) Press the <ENTER> button.
f The [WHITE BALANCE] screen is displayed.
7) Press as to select [WHITE BALANCE HIGH] or [WHITE BALANCE LOW].
8) Press the <ENTER> button.
f The [WHITE BALANCE HIGH] screen or the [WHITE BALANCE LOW] screen is displayed.
9) Press as to select [RED], [GREEN], or [BLUE].
10) Press qw to adjust the level.
Item Operation Adjustment Range of adjustment
[RED]
Press w.
Deepens red.
[WHITE BALANCE HIGH]: 0 - +255 (factory default is
+255)
[WHITE BALANCE LOW]:
- 127 - +127 (factory default is
0)
Press q.
Weakens red.
[GREEN]
Press w.
Deepens green.
Press q.
Weakens green.
[BLUE]
Press w.
Deepens blue.
Press q.
Weakens blue.
Note
f Adjust [COLOR TEMPERATURE] correctly. All colors will not be displayed properly unless adequate adjustment is made. If the adjustment
does not look suitable, you can press the <DEFAULT> button on the remote control to return the setting for the selected item only to the
factory default setting.
Adjusting desired white balance based on existing color temperature settings
1) Press as to select [COLOR TEMPERATURE].
2) Press qw or the <ENTER> button.
f The [COLOR TEMPERATURE] individual adjustment screen is displayed.
3) Press qw to select an item other than [DEFAULT], [USER1], and [USER2].
4) Press the <ENTER> button.
f The [CHANGE TO *****] screen is displayed.
5) Press as to select [USER1] or [USER2].
f The status of the color temperature changed is saved to the selected item.
