Operation Manual

Chapter 6 Appendix — Specications
ENGLISH - 213
r Applicable scanning frequency
Refer to “List of compatible signals” (x page 206) for the types of video signals that can be used with the
projector.
For video signal, Y/C signal Horizontal: 15.75 kHz, Vertical: 60 Hz; Horizontal: 15.63 kHz, Vertical: 50 Hz
For RGB signal
Horizontal: 15 kHz to 100 kHz, Vertical: 24 Hz to 120 Hz
PIAS (Panasonic Intelligent Auto Scanning) system
f Dot clock frequency: 162 MHz or less
For YC
B
C
R
/YP
B
P
R
signal
f 525i (480i)
Horizontal: 15.73 kHz, Vertical: 59.94 Hz
f 525p (480p)
Horizontal: 31.47 kHz, Vertical: 59.94 Hz
f 750 (720)/60p
Horizontal: 45 kHz, Vertical: 60 Hz
f 1125 (1035)/60i
Horizontal: 33.75 kHz, Vertical: 60 Hz
f 1125 (1080)/50i
Horizontal: 28.13 kHz, Vertical: 50 Hz
f 1125 (1080)/24sF
Horizontal: 27 kHz, Vertical: 48 Hz
f 1125 (1080)/30p
Horizontal: 33.75 kHz, Vertical: 30 Hz
f 1125 (1080)/50p
Horizontal: 56.25 kHz, Vertical: 50 Hz
f 625i (576i)
Horizontal: 15.63 kHz, Vertical: 50 Hz
f 625p (576p)
Horizontal: 31.25 kHz, Vertical: 50 Hz
f 750 (720)/50p
Horizontal: 37.5 kHz, Vertical: 50 Hz
f 1125 (1080)/60i
Horizontal: 33.75 kHz, Vertical: 60 Hz
f 1125 (1080)/24p
Horizontal: 27 kHz, Vertical: 24 Hz
f 1125 (1080)/25p
Horizontal: 28.13 kHz, Vertical: 25 Hz
f 1125 (1080)/60p
Horizontal: 67.5 kHz, Vertical: 60 Hz
f The SYNC/HD and VD terminals do not support 3 value SYNC.
For DVI-D signal
525i (480i)
*1
, 625i (576i)
*1
, 525p (480p), 625p (576p), 750 (720)/60p,
750 (720)/50p, 1125 (1080)/60i, 1125 (1080)/50i, 1125 (1080)/24p,
1125 (1080)/24sF, 1125 (1080)/25p, 1125 (1080)/30p,
1125 (1080)/60p, 1125 (1080)/50p
f Displayable resolution: 640 x 480 to 1 920 x 1 200 (non-interlaced)
f Dot clock frequency: 25 MHz to 162 MHz
For HDMI signal
525i (480i)
*1
, 625i (576i)
*1
, 525p (480p), 625p (576p), 750 (720)/60p,
750 (720)/50p, 1125 (1080)/60i, 1125 (1080)/50i, 1125 (1080)/24p,
1125 (1080)/24sF, 1125 (1080)/25p, 1125 (1080)/30p,
1125 (1080)/60p, 1125 (1080)/50p
f Displayable resolution: 640 x 480 to 1 920 x 1 200 (non-interlaced)
f Dot clock frequency: 25 MHz to 162 MHz
For SDI signal
SD-SDI signal SMPTE ST 259 compliant
YC
B
C
R
4:2:2 10-bit
480i, 576i
Single link HD-SDI signal SMPTE ST 292 compliant
YP
B
P
R
4:2:2 10-bit
720/50p, 720/60p, 1035/60i, 1080/50i, 1080/60i, 1080/25p,
1080/24p, 1080/24sF, 1080/30p
Dual link HD-SDI signal SMPTE ST 372 compliant
RGB 4:4:4 12-bit/10-bit
1080/50i, 1080/60i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p,
2048 x 1080/24p, 2048 x 1080/24sF
X'Y'Z' 4:4:4 12-bit
2048 x 1080/24p, 2048 x 1080/24sF
3G-SDI signal SMPTE ST 424 compliant
YP
B
P
R
4:2:2 10-bit
1080/50p, 1080/60p
RGB 4:4:4 12-bit/10-bit
1080/50i, 1080/60i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p
Dual link 3G-SDI signal SMPTE ST 425 compliant
YP
B
P
R
4:4:4 12-bit/10-bit
1080/60p, 1080/50p, 2048 x 1080/60p, 2048 x 1080/50p,
2048 x 1080/48p
RGB 4:4:4 12-bit/10-bit
1080/60p, 1080/50p, 2048 x 1080/60p, 2048 x 1080/50p,
2048 x 1080/48p
*1 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
Note
f DIGITAL LINK input compatible signal is the same as HDMI input compatible signal.
