Operation Manual

Chapter 6 Appendix — Specications
212 - ENGLISH
Specications
The specications of the projector are as follows.
Power supply
100 V - 240 V ~ (100 V - 240 V alternating current), 50 Hz/60 Hz
Power consumption
1 200 W (12.0 A - 6.0 A)
When [STANDBY MODE] is set to [ECO]: 0.3 W
When [STANDBY MODE] is set to [NORMAL]: 4 W
DLP chip
Size
PT-RZ12K 24.4 mm (0.96") (aspect ratio 16:10)
PT-RS11K 24.1 mm (0.95") (aspect ratio 4:3)
Display system DLP chip x 3, DLP projection system
Number of pixels
PT-RZ12K 2 304 000 pixels (1 920 x 1 200 dots)
PT-RS11K 1 470 000 pixels (1 400 x 1 050 dots)
Lens Optional
Light source Laser, 2-bank type
Light output
*1
12 000 lm (ANSI)
Contrast ratio
*1
20 000:1 (when [DYNAMIC CONTRAST] is set to [3])
Color system 7 standards (NTSC/NTSC4.43/PAL/PAL-N/PAL-M/SECAM/PAL60)
Projected image size 1.78 m (70") to 25.40 m (1 000")
*2
Image aspect ratio
PT-RZ12K 16:10
PT-RS11K 4:3
Projection method [FRONT/CEILING], [FRONT/FLOOR], [REAR/CEILING], [REAR/FLOOR]
Power cord length 3.0 m (118-1/8")
Outer case Molded plastic
Dimensions
Width 578 mm (22-3/4")
Height 270 mm (10-5/8") (excluding the feet)
Depth 725 mm (28-17/32") (excluding the protrusion)
Weight
Approx. 44.0 k] (96.9 lbs.)
*3
Noise level
*1
43 dB
Operating
environment
Operating
environment
temperature
0 °C (32 °F) to 50 °C (122 °F)
*4
Operating
environment
humidity
10 % to 80 % (no condensation)
Remote
control
Power supply DC 3 V (AA/R6/LR6 battery x 2)
Operating range Within approx. 30 m (98'5") (when operated directly in front of signal receiver)
Weight
150 ] (5.3 ozs.) (including batteries)
Dimensions Width: 47.5 mm (1-7/8"), Height: 181.5 mm (7-5/32"), Depth: 27.5 mm (1-3/32")
*1 Measurement, measuring conditions and method of notation all comply with ISO21118 international standards.
*2 When the Zoom Lens (Model No.: ET-D75LE8) is used, the projected image size for the maximum projection distance will be 1.78 m (70") to
15.24 m (600"). When the Fixed-focus Lens (Model No.: ET-D75LE90) is used, the projected image size for the maximum projection distance will be
3.05 m (120") to 15.24 m (600").
*3 Average value. Weight varies for each product.
*4 The operating environment temperature should be between 0 °C (32 °F) and 45 °C (113 °F) if the projector is used at an altitude between 1 400 m
(4 593') and 4 200 m (13 780') above sea level. However, when [OPERATING MODE] in the [PROJECTOR SETUP] menu → [OPERATION
SETTING] is set to [ECO], [LONG LIFE1], [LONG LIFE2], or [LONG LIFE3], the operating environment temperature should be between 0 °C (32 °F)
and 45 °C (113 °F), and when the Smoke Cut Filter is used, it should be between 0 °C (32 °F) and 40 °C (104 °F).
When [OPERATING MODE] in the [PROJECTOR SETUP] menu → [OPERATION SETTING] is set to [ECO], [LONG LIFE1], [LONG LIFE2], or
[LONG LIFE3], the projector cannot be used at an altitude of 2 700 m (8 858') or higher above sea level. When the Smoke Cut Filter is used, the
projector cannot be used at an altitude of 1 400 m (4 593') or higher above sea level.
