List of compatible signals
The following table species the video signals compatible with the projector.
f Symbols that indicate formats are as follows.
g V: VIDEO, Y/C
g R: RGB
g Y: YC
B
C
R
/YP
B
P
R
g D: DVI-D
g H: HDMI
g S: SDI
Compatible signal
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Format
Plug and play
*1
Horizontal
(kHz)
Vertical
(Hz)
RGB2
DVI-D
HDMI
EDID1 EDID2 EDID3
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.7 59.9 ― V ― ― ― ― ―
PAL/PAL-N/SECAM 720 x 576i 15.6 50.0 ― V ― ― ― ― ―
525i (480i) 720 x 480i 15.7 59.9 13.5 R/Y/S
*2
― ― ― ― ―
625i (576i) 720 x 576i 15.6 50.0 13.5 R/Y/S
*2
― ― ― ― ―
525i (480i) 720 (1440) x 480i
*3
15.7 59.9 27.0 D/H ― ― ― ― ―
625i (576i) 720 (1440) x 576i
*3
15.6 50.0 27.0 D/H ― ― ― ― ―
525p (480p) 720 x 483 31.5 59.9 27.0 R/Y/D/H ―
l
―
l l
625p (576p) 720 x 576 31.3 50.0 27.0 R/Y/D/H ―
l
―
l l
750 (720)/60p 1 280 x 720 45.0 60.0 74.3 R/Y/D/H/S
*2
―
l
―
l l
750 (720)/50p 1 280 x 720 37.5 50.0 74.3 R/Y/D/H/S
*2
―
l
―
l l
1125 (1080)/60i
*4
1 920 x 1 080i 33.8 60.0 74.3 R/Y/D/H/S ―
l
―
l l
1125 (1080)/50i 1 920 x 1 080i 28.1 50.0 74.3 R/Y/D/H/S ―
l
―
l l
1125 (1080)/24p 1 920 x 1 080 27.0 24.0 74.3 R/Y/D/H/S ―
l
―
l l
1125 (1080)/24sF 1 920 x 1 080i 27.0 48.0 74.3 R/Y/D/H/S ― ― ― ― ―
1125 (1080)/25p 1 920 x 1 080 28.1 25.0 74.3 R/Y/D/H/S ―
l
―
l
―
1125 (1080)/30p 1 920 x 1 080 33.8 30.0 74.3 R/Y/D/H/S ― ― ― ― ―
1125 (1080)/60p 1 920 x 1 080 67.5 60.0 148.5 R/Y/D/H/S ―
l
―
l l
1125 (1080)/50p 1 920 x 1 080 56.3 50.0 148.5 R/Y/D/H/S ―
l
―
l l
2K/24p 2 048 x 1 080 27.0 24.0 74.3 S
*5
― ― ― ― ―
2K/24sF 2 048 x 1 080 27.0 24.0 74.3 S
*5
― ― ― ― ―
2K/48p 2 048 x 1 080 54.0 48.0 148.5 S
*6
― ― ― ― ―
2K/50p 2 048 x 1 080 56.3 50.0 148.5 S
*6
― ― ― ― ―
2K/60p 2 048 x 1 080 67.5 60.0 148.5 S
*6
― ― ― ― ―
640 x 400
640 x 400 31.5 70.1 25.2 R/D/H ― ― ― ― ―
640 x 400 37.9 85.1 31.5 R/D/H ― ― ― ― ―
640 x 480
640 x 480 31.5 59.9 25.2 R/D/H
l l l l l
640 x 480 35.0 66.7 30.2 R/D/H ― ― ― ― ―
640 x 480 37.9 72.8 31.5 R/D/H
l
―
l l l
640 x 480 37.5 75.0 31.5 R/D/H
l
―
l l l
640 x 480 43.3 85.0 36.0 R/D/H ― ― ― ― ―
800 x 600
800 x 600 35.2 56.3 36.0 R/D/H
l
―
l l l
800 x 600 37.9 60.3 40.0 R/D/H
l
―
l l l
800 x 600 48.1 72.2 50.0 R/D/H
l
―
l l l
800 x 600 46.9 75.0 49.5 R/D/H
l
―
l l l
800 x 600
53.7 85.1 56.3 R/D/H ― ― ― ― ―
832
x 624 832 x 624 49.7 74.6 57.3 R/D/H
l
―
l l l
