Operation Manual

Chapter 6 Appendix — Technical information
ENGLISH - 195
Control details Performance Parameter Default value Remark
POWER
Standby 0-63
128 ―No operation 64-191
Power on 192-255
SHUTTER
SHUTTER: Open 0-63
128 ―No operation 64-191
SHUTTER: Close 192-255
FADE-IN
FADE-OUT
(when [1] is selected)
0.0s 0-15
255
Operate together with
CHANNEL1.
0.5s 16-31
1.0s 32-47
1.5s 48-63
2.0s 64-79
2.5s 80-95
3.0s 96-111
3.5s 112-127
4.0s 128-143
5.0s 144-159
7.0s 160-175
10.0s 176-191
No operation 192-255 ―
GEOMETRY
OFF 0-15
255 ―
KEYSTONE 16-31
CURVED 32-47
PC-1 48-63
PC-2 64-79
PC-3 80-95
CORNER CORRECTION 96-111
No operation 112-255
CUSTOM MASKING
OFF 0-31
255
To use PC-1, PC-2, and PC-3, the
optional Upgrade Kit (Model No.:
ET-UK20) is required.
PC-1 32-63
PC-2 64-95
PC-3 96-127
No operation 128-255
FREEZE
No operation 0-31
128 ―
OFF 32-95
No operation 96-159
ON 160-223
No operation 224-255
COLOR
TINT
No operation 0-31
0 ―
Factory default setting 32-63
- 31 64-65
… …
0 128-129
… …
[phone]
No operation 192-255
RASTER PATTERN
No operation 0-15
0 ―
OFF 16-31
WHITE 32-47
YELLOW 48-63
CYAN 64-79
GREEN 80-95
MAGENTA 96-111
RED 112-127
BLUE 128-143
BLACK 144-159
USER LOGO 160-175
No operation 176-255
