Operation Manual

Chapter 6 Appendix — Technical information
194 - ENGLISH
Control details Performance Parameter Default value Remark
INPUT SELECT (when [2] or
[USER] is selected)
No operation 0-7
0 ―
RGB1 8-15
RGB2 16-23
DVI-D 24-31
HDMI 32-39
DIGITAL LINK 40-47
SDI1 48-55
SDI2 56-63
No operation 64-119
P IN P OFF 120-127
P IN P execution, USER1 128-135
P IN P execution, USER2 136-143
P IN P execution, USER3 144-151
No operation 152-255
LENS POSITION
No operation 0-31
0
“Move to the home position” is
an operation when [NORMAL] is
selected in [HOME POSITION] of
the [HOME POSITION] screen.
“Move to the ET-D75LE90 lens
standard position” is an operation
when [D75LE90] is selected in
[HOME POSITION] of the [HOME
POSITION] screen.
Move to the home position
32-63
Move to the ET-D75LE90 lens
standard position
Load LENS MEMORY 1 64-79
Load LENS MEMORY 2 80-95
Load LENS MEMORY 3 96-111
Load LENS MEMORY 4 112-127
Load LENS MEMORY 5 128-143
Load LENS MEMORY 6 144-159
Load LENS MEMORY 7 160-175
Load LENS MEMORY 8 176-191
Load LENS MEMORY 9 192-207
Load LENS MEMORY 10 208-223
No operation 224-255
LENS H SHIFT
LENS V SHIFT
LENS FOCUS
LENS ZOOM
Lens adjustment
(
- ) High speed 0-31
128 ―
(
- ) Low speed 32-63
(
- ) Fine
adjustment
64-95
Operation stop 96-159
Lens adjustment
(+) Fine
adjustment
160-191
(+) Low speed 192-223
(+) High speed 224-255
LENS FUNCTION SELECT
(when [1] is selected)
No operation 0-15
0
Operate together with LENS
CONTROL.
“Move to the home position” is
an operation when [NORMAL] is
selected in [HOME POSITION] of
the [HOME POSITION] screen.
“Move to the ET-D75LE90 lens
standard position” is an operation
when [D75LE90] is selected in
[HOME POSITION] of the [HOME
POSITION] screen.
LENS H SHIFT 16-31
LENS V SHIFT 32-47
LENS FOCUS 48-63
LENS ZOOM 64-79
Move to the home position
80-95
Move to the ET-D75LE90 lens
standard position
No operation 96-255
LENS CONTROL (when [1] is
selected)
Lens adjustment
(
- ) High speed 0-31
100
Operate together with LENS
FUNCTION SELECT.
(
- ) Low speed 32-63
(
- ) Fine
adjustment
64-95
Operation stop 96-127
Lens adjustment
(+) Fine
adjustment
128-159
(+) Low speed 160-191
(+) High speed 192-223
Execute command action 224-255
