Operation Manual

Chapter 4 Settings — [TEST PATTERN] menu
148 - ENGLISH
[TEST PATTERN] menu
On the menu screen, select [TEST PATTERN] from the main menu.
Refer to “Navigating through the menu” (x page 76) for the operation of the menu screen.
[TEST PATTERN]
Display the test pattern built-in to the projector.
Settings of position, size, and other factors will not be reected in test patterns. Make sure to display the input
signal before performing various adjustments.
1) Press qw to switch the [TEST PATTERN] item.
f The items will switch each time you press the button.
Menu screen + All white
Displays test patterns with the menu screen. Select a test pattern so that it is easy to make various
adjustments.
Menu screen + All black
Menu screen + Window
Menu screen + Window
(inversion)
Menu screen + Color bar
(vertical)
Menu screen + Color bar
(horizontal)
Menu screen + 16:9/4:3
aspect frame
Menu screen + Focus
Menu screen + Input screen
Displays the menu screen and input signal.
Built-in test patterns are not displayed.
Note
f Press the <ON SCREEN> button on the remote control while the test pattern is displayed to hide the menu screen.
Changing color or a focus test pattern
The color can be changed when the “Menu screen + Focus” test pattern is displayed.
1) Press qw to select the “Menu screen + Focus” test pattern.
2) Press the <ENTER> button.
f The [TEST PATTERN COLOR] screen is displayed.
3) Press as to select a color, and press the <ENTER> button.
f The color of the focus test pattern will be changed to the selected color.
Note
f The test pattern color settings return to [WHITE] when the projector is switched off.
f Colors of the test patterns other than focus test patterns cannot be changed.
